■Characteristics graph

Analogue output (Flow)
(PF3W504/520/540)
A
Voltage
1 V 1.5 V
output
Current
4 mA 6 mA
output
(PF3W511)
A
Voltage
1 V 1.4 V
output
Current
4 mA 5.6 mA
output
(PF3W521)
A
Voltage
1 V 1.5 V
output
Current
4 mA 5.9 mA
output
Rated flow [L/min]
Sensor
model
Min.
PF3W504 0.5
PF3W520 2
PF3W540 5
PF3W511 10
PF3W521 30
Analogue output (Fluid temperature)
A
Voltage
0.6 V
output
Current
2.4 mA 4 mA
output
Be sure to connect to a flow sensor with a
temperature sensor.
B C
5 V
20 mA
B C
5 V
20 mA
B C
5 V
20 mA
Max.
4
16
40
100
250
B C D
1 V 5 V 5.4 V
20 mA 21.6 mA
