SMC Networks PF3W3 Series Operation Manual page 37

<Operation>
1. Selection of output mode
Press the or button in function selection mode to display [F 2] on the main screen.
The sub screen displays [oUt2] and the currently set output mode alternately.
∗: If OUT2 is not provided, the display will be [---].
Press the button.
Sub screen
Press the
Press the
2. Setting of switch operation
Sub screen
Press the
or button to select the output mode.
button to confirm.
Press the or
button to confirm.
-37-
Move on to the setting of switch operation.
button to select switch operation.
Move on to the input of set values.
(ON and OFF points)
No.PF※※-OMN0012-I
