■[F98] Output check
The output check can be turned on irrespective of flow conditions so that the circuit wiring can be checked.
For the analogue output type, when ON the output will be 5 V or 20 mA, and when OFF 1 V or 4 mA.
<Operation>
Press the or
Press the
Sub screen
NoRMAL
The check of
OUT1
Changing the display between ON and OFF (using the
or
The check of
OUT2
Return to the function selection mode.
[F98] Setting of output check is completed.
∗: Press the button for 2 seconds or longer to return to measurement mode.
∗: An increase or decrease in flow will have no effect on the output while the output check function is being performed.
button in function selection mode to display [F98] on the main screen.
button.
Press the or
Sub screen
button) also changes the output status.
Press the
Sub screen
For analogue output
ON: 5 V or 20 mA
OFF: 1 V or 4 mA
Normal output:
The output acts in accordance with the set
values.
to select.
FoRCE
∗
button.
-59-
No.PF※※-OMN0012-I
