SMC Networks PF3W3 Series Operation Manual page 69

Model
Hysteresis
External input
Input/Output
Display method
Indicator light
Power supply voltage
Current consumption
Connection
Enclosure
Operating temp.
range
Operating
humidity range
Withstand voltage
Insulation
resistance
Standards and
regulations
Without lead wire
With lead wire
∗1: The accumulated value will be cleared by turning off the power supply. It is possible to select the function to memorize it.
(Every 2 or 5 minutes.)
When 5 minutes interval is selected, take into consideration the maximum number of times it is possible to write to the memory device
(electronic part), which is 1 million times (5 minutes x 1 million times = 5 million minutes = Approx. 9.5 years for 24 hour energizing).
Calculate the life in your operating conditions before using the memorizing function and use within this range.
∗2: The response time is when the set value is 90% in relation to the step input. (The value will be 7 s for the temperature sensor output.)
∗3: The response time is when the set value reaches 90% in relation to the step input and linked with the switch output. (The value will be
7 s for the temperature sensor output.)
Specifications of lead wire (ZS-40-W)
Items
Nominal cross-section area
Conductor
Outside diameter
Outside diameter
Insulator
Colours
Sheath Outer diameter
Voltage free input of 0.4 V or less (reed or solid state type) for 30 ms or longer
(Main screen: 4-digit, 7-segment, 2-colour; red/green,
Sub screen: 6-digit, 11-segment, white)
Display updating frequency 5 times/sec.
Power supply output 5P connector, sensor connection 4P connector (e-con)
IP40 (Note that the display front is only certified as IP65 by using optional parts (panel
mount adapter and waterproof seal)).
0 to 50
Operation, Storage: 35 to 85%R.H. (No condensation)
1000 VAC, 1 minute between the terminals and housing
50 MΩ min. (with 500 VDC) between the terminals and housing
CE/UKCA marked (EMC directive, RoHS directive), UL(CSA)
Specifications
Approx. 0.51 mm
Approx. 1.00 mm
Brown, blue, black, white and grey
-69-
PF3W30#
Variable
Input for copy mode
2-screen display
Output 1 and 2: Orange
12 to 24 VDC ±10%
50 mA max.
o C (No freezing and condensation)
50 g
100 g
AWG26
φ3.5 mm
No.PF※※-OMN0012-I
