<Operation of the set value change> (3 step setting mode)
∗: Be sure to select the correct sensor to be connected. (Refer to page 27.)
1. Press the button in measurement mode to display set values.
2. [P_1] or [n_1] and the set value are displayed alternately.
3. Press the
or
The button is to increase and the
•Press the button once to increase by one digit, or press and hold to continuously increase.
•Press the button once to decrease by one digit, or press and hold to continuously decrease.
4. Press the button to finish the setting.
∗: For models with switch outputs for both OUT1 and OUT2, [ tn] or [ tp] will be displayed too. Set as above.
∗: For models with the temperature sensor attached, [P_2] or [n_2] will be displayed too. Set as above.
∗: For input of hysteresis, perform the settings referring to [F 1] Setting of OUT1 (page 28) and [F 2] Setting of OUT2 (page 36).
∗: When a mode other than hysteresis mode is selected, "Set value" of page
∗: Note that the set value and hysteresis are limited by each other.
∗: For more detailed settings, set each function in function selection mode (page 25).
button to change the set value.
button is to decrease the set value.
30 is displayed.
-24-
No.PF※※-OMN0012-I
