SMC Networks PF3W3 Series Operation Manual page 58

Sending/
Receiving
Copy
completed
∗: They may not flash due to the timing.
Press the
button.
Successive copy is possible.
The copy ready status is held even if the
power supply is turned off.
When completing copy function, press
the and buttons
simultaneously for 1 second at least.
∗: It the copy to the copy destination flow monitor is not completed, it is detected as a copying function sending/receving error. Press
the and buttons simultaneously for 1 second at least to return to the measurement mode. Then, check the wiring of the
switch and retry copy function.
Copy source flow monitor
Flashing
(Red)
Lights up
(Red)
[F97] Selection of copy function is completed.
Copy destination flow monitor
∗
∗: Press the and
buttons simultaneously
for 1 second at least.
Return to the measurement mode.
-58-
Flashing
∗
(Green)
Press the
button.
No.PF※※-OMN0012-I
