SMC Networks PF3W3 Series Operation Manual page 70

Specifications of temperature sensor
Items
Rated temperature range
Setting/display temperature range
Min. setting unit
Display unit
Analogue output accuracy
Response time
Ambient temperature characteristics
∗1: The rated temperature range is only for the temperature sensor. As a whole product, the fluid temperature range is specified as 0 to
90 o C.
∗2: The response time is only for the temperature sensor.
Flow specification of the specified order (flow unit: gal)
Model
Rated flow range
Display flow
range
Setting flow
range
Min. setting/
display unit
Setting/display
99999999.9 gal
flow unit
Min. setting/
diplay unit
Conversion of
accumulated pulse
Temperature specification of the specified order (temp. unit:
Rated temperature range
Setting/display temperature range
Min. setting/display unit
∗: The rated temperature range is only for the temperature sensor. As a whole product, the fluid temperature range is specified as 0 to 90
PF3W504 PF3W520
0.13 to 1.06 0.53 to 4.23
gal/min gal/min
0.09 to 1.18 0.45 to 4.75
gal/min gal/min
(Flow under (Flow under
0.09 L/min is 0.45 L/min is
displayed as displayed as
"0.00".) "0.00".)
0.09 to 1.18 0.45 to 4.75
gal/min gal/min
0.01 gal/min
0.1 gal
0.01 gal/palse 0.05 gal/palse
32 to 212
∗
14 to 230
Specifications
0 to 100 o C ∗1
-10 to 110 o C
1 C
o
o C
±3%F.S.
7 s ∗2
±5%F.S.
PF3W540
1.3 to 10.6
gal/min
0.9 to 11.8
gal/min
(Flow under
0.9 L/min is
displayed as
"0.0".)
0.9 to 11.8
gal/min
0.1 gal/min
999999999 gal
1 gal
0.1 gal/palse
F)
o
o F
o F
1 o F
-70-
PF3W511 PF3W521
2.6 to 26.4 13 to 66
gal/min gal/min
1.8 to 29.5 5 to 73
gal/min gal/min
(Flow under
(Flow under
1.8 L/min is 5 L/min is
displayed as displayed as
"0.0".) "0".)
1.8 to 29.5 5 to 73
gal/min gal/min
1 gal/min
0.5 gal/palse 1 gal/palse
No.PF※※-OMN0012-I
o C.
