Setting the Odometer

While scrolling through 'CAL' mode you will see 'ODO' appear. This will allow you to enter the
vehicle's actual mileage. Press the trip button again at this point and you will enter the odometer set up
mode. Press quickly to change the number of the digit on the right. Press and hold to advance to the next
digit. Do this for all 5 digits. For Example: To enter the mileage reading.
23456 into the odometer, at the 'ODO' prompt, tap the small black button (quickly) two times, until the
number 2 is dis- played. Then press and hold the button until the numbers 20 are displayed. Tap the
button 3 times until 23 is displayed. Press and hold the button until 230 is displayed and continue in this
manner until 23456 is displayed. The speedometer will advance to the home screen, five seconds after the
last number is entered.
Recording and Viewing Performance Data
Follow these steps to record and recall Performance Data (high speed, ¼mile ET, and 0-60 time):
Before each run, your car must be at a complete stop at the starting position. Press and hold
1.
the pushbutton as it cycles through the performance data. At the end, the odometer will re-set and
all performance data will be cleared. This will not affect your stored calibration value or the
odometer reading.
Press the push-button until 'HI-SP' is displayed. The gauge will automatically cycle through
2.
the performance data.
Start the run, pass, session, etc., as mentioned above.
3.
When finished, repeat Step 2 to view the data gathered from the run. While stopped, you can
4.
view this data as often as you wish. However, once it finishes scrolling one time, the memory is
ready to record new data and will begin recording again once the vehicle starts to move. The
highest speed measured over multiple runs will be retained in memory.
SPEEDOMETER CALIBRATION PROCEDURE
The Digital Performance Speedometer leaves the factory with a factory pre-set industry standard
setting of 8,000 pulses per mile. It can be calibrated with the push-button to adjust the speedometer
when you have different tire sizes, wheel sizes, and gear ratios. You should not have to
recalibrate your speedometer unless you have changed the original tire size or the rear end
gear ratio. You will have to calibrate your speedometer if you are using km/h. You will follow the
procedure using a measure kilometer.
To enter calibration: When the display is scrolling through the function menu you will press the button
briefly one time when 'CAL' is being displayed. '8000' will appear in the odometer, this indicates the
factory settings, when the button is pressed, this will change to '0'. When the '0' is displayed the gauge is
ready to be calibrated. It is very important that you drive to the end of the measured mile and tap the
button again. At a minimum, drive some distance and you can always go back and start again if need be. If
you miss stopping the display at 'CAL', simply repeat the steps.
Warning: If the microprocessor does not receive any data, the unit will display 'Err" and will revert to the
factory settings. This can be the result of not moving the vehicle while in 'CAL' mode or the dash is not
receiving a proper speed signal from the vehicle.
