3.) Speedometer - White (Intellitronix Speed Sender to replace factory cable drive) -
Disconnect the mechanical speedometer cable from the transmission and insert the new
electronic sensor into the transmission. This panel comes with a 3-wire sensor.
Follow this wiring for the Intellitronix speedometer sending unit:
White -Wire is the speed signal; connect this to the white wire on the sender.
Red/White – Wire is power for the sender will be wired to Red wire on your sender.
Black/White - Wire is ground for the sender will be wired to the Black wire on the sender.
*If working with a factory VSS or computer based angine you will NOT use the black/white or
red/white wires

Trip Distance

A single tap of the recall button will activate the trip meter in the odometer display. A decimal
point will appear which will indicate that you are in trip meter mode. Holding the recall button
will clear out the trip distance. To return to the default odometer display, tap the recall button
again. The decimal point will disappear, indicating that you are back in the default odometer
display.

Setting the Odometer

While scrolling through 'CAL' mode you will see 'ODO' appear. This will allow you to enter the
vehicle's actual mileage. Press the trip button again at this point and you will enter the odometer
set up mode. Press quickly to change the number of the digit on the right. Press and hold to
advance to the next digit. Do this for all 5 digits. For Example: To enter the mileage reading.
23456 into the odometer, at the 'ODO' prompt, tap the small black button (quickly) two times,
until the number 2 is dis- played. Then press and hold the button until the numbers 20 are
displayed. Tap the button 3 times until 23 is displayed. Press and hold the button until 230 is
displayed and continue in this manner until 23456 is displayed. The speedometer will advance to
the home screen, five seconds after the last number is entered.
Recording and Viewing Performance Data
Follow these steps to record and recall Performance Data (high speed, ¼mile ET, and 0-60 time):
Before each run, your car must be at a complete stop at the starting position. Press and hold
1.
the pushbutton as it cycles through the performance data. At the end, the odometer will re-
set and all performance data will be cleared. This will not affect your stored calibration
value or the odometer reading.
Press the push-button until 'HI-SP' is displayed. The gauge will automatically cycle through
2.
the performance data.
Start the run, pass, session, etc., as mentioned above.
3.
When finished, repeat Step 2 to view the data gathered from the run. While stopped, you
4.
can view this data as often as you wish. However, once it finishes scrolling one time, the
memory is ready to record new data and will begin recording again once the vehicle starts
to move. The highest speed measured over multiple runs will be retained in memory.
SPEEDOMETER CALIBRATION PROCEDURE
The Digital Performance Speedometer leaves the factory with a factory pre-set industry
standard setting of 8,000 pulses per mile. It can be calibrated with the push-button to adjust
the speedometer when you have different tire sizes, wheel sizes, and gear ratios. You
should not have to recalibrate your speedometer unless you have changed the original
