* Always disconnect the battery before attempting any electrical work on your vehicle. *
KIT COMPONENTS
◊ One (1) Digital Circuit Board (with Speedometer, Tachometer, Fuel,
Water Temp, Voltmeter, and Oil Pressure Gauges)
◊ One (1) Smoked Acrylic Lens
* Peel off protective covering from both sides
One (1) Oil pressure sending unit (S8868)
*1/8" NPT, 0-100 PSI Oil Pressure
One (1) Temperature sending unit
*1/8" NPT, 1/2" NPT Bushing
◊ One (1) Mounting Kit:
• Four (4) 4 x 7/8" recessed Phillips's head screws and nuts
• Four (4) 4 x 3/8" nylon spacers.
1 – DP7009
INSTALLATION GUIDE
Ford Mustang Digital Dash Panel
Part Number: DP7009
Year Series: 1994-2004
Rev (10/01/2021)
www.intellitronixgauges.com
Advertisement
Related Manuals for Intellitronix DP7009
Summary of Contents for Intellitronix DP7009
- Page 1 INSTALLATION GUIDE Ford Mustang Digital Dash Panel Part Number: DP7009 Year Series: 1994-2004 * Always disconnect the battery before attempting any electrical work on your vehicle. * KIT COMPONENTS ◊ One (1) Digital Circuit Board (with Speedometer, Tachometer, Fuel, Water Temp, Voltmeter, and Oil Pressure Gauges) ◊...
-
Page 2: Wiring Instructions
Do not use Teflon tape or other sealer on the new sending unit’s threads to avoid inaccurate readings. Connect the blue wire to the sending unit. 2 – DP7009 Rev (10/01/2021) www.intellitronixgauges.com... - Page 3 Ground at the Engine block. To find High and Low output wire color or pin location will need to be looked up by Vehicle vin or Model and year or (Consults Pinout Chart Speedometer - White (Intellitronix Speed Sender) - Disconnect the mechanical speedometer cable from the transmission and thread the new electronic sensor onto the transmission. This panel comes with a 3-wire sensor.
- Page 4 Note: If doing a LS engine swap, pick up the tach signal wire from the ECM/ECU and then set the tach switch to 4-cylinders. You may also need to order the Intellitronix LS Engine Swap Adapter Kit – for Series 1, 2 and 3 engines. The part number is 8014LS. If you are getting the tach signal from the ECU, the resistor in the adapter kit will help pull a stronger signal for the tachometer.
- Page 5 DIGITAL PERFORMANCE SPEEDOMETER Note: If using the Intellitronix GPS Sending Unit, (S9020 – not included) the speedometer does not need to be calibrated. The speedometer leaves the factory with a pre-set industry standard setting of 8,000 pulses per mile. Chances are that you may not need to recalibrate your speedometer, unless you have changed the original tire size or the rear end gear ratio.
-
Page 6: Lifetime Guarantee
9am – 5pm EST (440) 359 – 7200 ext 109 support@intellitronix.com This product carries a limited Lifetime Warranty. This warranty is limited to replacement or repair of the unit at the discretion of Intellitronix. Made in America Lifetime Guarantee 6 – DP7009 Rev (10/01/2021) www.intellitronixgauges.com...
