Pin
Signal Name
Number
AE17 SFP+1_RS1
AE18 SFP+1_SCL
AF18 SFP+1_SDA
AF19 SFP+1_TX_DISABLE
AG19 SFP+1_TX_FAULT
AU30 SI5328_1V8_SCL
AU29 SI5328_1V8_SDA
AN32 SI5328_REFCLK_IN_N
AM32 SI5328_REFCLK_IN_P
W7 SI5328_REFCLK_OUT0_PIN_N
W8 SI5328_REFCLK_OUT0_PIN_P
K9 SI5328_REFCLK_OUT1_PIN_N
K10 SI5328_REFCLK_OUT1_PIN_P
AR20 SPARE_SCL
AT20 SPARE_SDA
AP16 SPARE_WP
AW19 SRVC_MD_L
AJ29
AT19 USER_LED_G0
AU19 USER_LED_G1
AU20 USER_LED_R
AV18 USR_SW
Table 15 : Complete Pinout Table
TE485
ADM-PCIE-8K5 User Manual
Bank Voltage
3.3
3.3
3.3
3.3
3.3
1.8
1.8
1.8
1.8
MGT_CLK
MGT_CLK
MGT_CLK
MGT_CLK
3.3
3.3
3.3
3.3
1.8
3.3
3.3
3.3
3.3
Complete Pinout Table
