Pin
Signal Name
Number
E15 DDR4_0_C1
J13 DDR4_0_C2
K12 DDR4_0_CK_C
K13 DDR4_0_CK_T
E16 DDR4_0_CKE
D15 DDR4_0_CS_N
D19 DDR4_0_DM0
D24 DDR4_0_DM1
L17 DDR4_0_DM2
T23 DDR4_0_DM3
H19 DDR4_0_DM4
H21 DDR4_0_DM5
K21 DDR4_0_DM6
P19 DDR4_0_DM7
P13 DDR4_0_DM8
B20 DDR4_0_DQ0
C18 DDR4_0_DQ1
A24 DDR4_0_DQ10
B24 DDR4_0_DQ11
B21 DDR4_0_DQ12
C23 DDR4_0_DQ13
D21 DDR4_0_DQ14
A22 DDR4_0_DQ15
J19 DDR4_0_DQ16
M17 DDR4_0_DQ17
K18 DDR4_0_DQ18
L19 DDR4_0_DQ19
B19 DDR4_0_DQ2
J18 DDR4_0_DQ20
M16 DDR4_0_DQ21
J20 DDR4_0_DQ22
L18 DDR4_0_DQ23
T22 DDR4_0_DQ24
R20 DDR4_0_DQ25
P23 DDR4_0_DQ26
N23 DDR4_0_DQ27
Table 15 : Complete Pinout Table (continued on next page)
ADM-PCIE-8K5 User Manual
Bank Voltage
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
Complete Pinout Table
