Alpha Data ADM-PCIE-8K5 User Manual page 31

ADM-PCIE-8K5 User Manual
Complete Pinout Table
ad-ug-1319_v1_12.pdf
Pin
Signal Name
Number
K15 DDR4_0_TEN
AG22 DDR4_1_A0
AE20 DDR4_1_A1
AH23 DDR4_1_A10
AH22 DDR4_1_A11
AF23 DDR4_1_A12
AF22 DDR4_1_A13
AK23 DDR4_1_A14
AE21 DDR4_1_A15
AL22 DDR4_1_A16
AF20 DDR4_1_A17
AL20 DDR4_1_A2
AJ23 DDR4_1_A3
AK21 DDR4_1_A4
AM20 DDR4_1_A5
AN21 DDR4_1_A6
AD21 DDR4_1_A7
AG21 DDR4_1_A8
AP20 DDR4_1_A9
AR23 DDR4_1_ACT_N
AJ20 DDR4_1_ALERT_N
AK22 DDR4_1_BA0
AK20 DDR4_1_BA1
AN23 DDR4_1_BG0
AE23 DDR4_1_BG1
AN24 DDR4_1_C0
AP24 DDR4_1_C1
AP23 DDR4_1_C2
AR21 DDR4_1_CK_C
AP21 DDR4_1_CK_T
AL23 DDR4_1_CKE
AR22 DDR4_1_CS_N
AV24 DDR4_1_DM0
AV28 DDR4_1_DM1
AK27 DDR4_1_DM2
AD25 DDR4_1_DM3
Table 15 : Complete Pinout Table (continued on next page)
Bank Voltage
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
Page 27
