Alpha Data ADM-PCIE-8K5 User Manual page 30

Page 26
Pin
Signal Name
Number
R16 DDR4_0_DQ60
N18 DDR4_0_DQ61
N16 DDR4_0_DQ62
N17 DDR4_0_DQ63
N14 DDR4_0_DQ64
R12 DDR4_0_DQ65
P15 DDR4_0_DQ66
P14 DDR4_0_DQ67
M14 DDR4_0_DQ68
R13 DDR4_0_DQ69
A17 DDR4_0_DQ7
L15 DDR4_0_DQ70
M15 DDR4_0_DQ71
C21 DDR4_0_DQ8
D23 DDR4_0_DQ9
B17 DDR4_0_DQS0_C
C17 DDR4_0_DQS0_T
B22 DDR4_0_DQS1_C
C22 DDR4_0_DQS1_T
J16 DDR4_0_DQS2_C
K16 DDR4_0_DQS2_T
N22 DDR4_0_DQS3_C
N21 DDR4_0_DQS3_T
E17 DDR4_0_DQS4_C
F17 DDR4_0_DQS4_T
F24 DDR4_0_DQS5_C
G24 DDR4_0_DQS5_T
M21 DDR4_0_DQS6_C
M20 DDR4_0_DQS6_T
T17 DDR4_0_DQS7_C
T18 DDR4_0_DQS7_T
M12 DDR4_0_DQS8_C
N12 DDR4_0_DQS8_T
D16 DDR4_0_ODT
H13 DDR4_0_PAR
A14 DDR4_0_RESET_N
Table 15 : Complete Pinout Table (continued on next page)
ADM-PCIE-8K5 User Manual
Bank Voltage
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
Complete Pinout Table
ad-ug-1319_v1_12.pdf
