Valtek Flowtop Modification; Safety; Packaging And Transport; Storage - Flowserve Valtek FlowTop V726 User Instructions

Valtek FlowTop

4 Valtek FlowTop Modification

Valtek FlowTop control valves are generally delivered as tested
and assembled units, with factory-mounted actuators.
Unauthorized modification of the Valtek Flow-
Top control valve voids the product test certi-
fication and product warranties, could drasti-
cally affect product performance, and could
be hazardous to personnel and equipment.
Before Valtek FlowTop re-use, all necessary
NOTICE
tests must be repeated and recorded in
compliance with all test routines, guidelines and engineering
standards.

5 Safety

Safety terms - WARNING and NOTICE - are used to highlight
specific dangers and / or provide additional information
that may not be readily apparent in the User Instructions.
WARNING directions must be strictly followed.
WARNING
death and substantial property damage can occur if proper
precautions are not taken.
NOTICE indicates practices or provides ad-
NOTICE
ditional technical information.
Green fields indicate safety-related informations.

6 Packaging and Transport

Pay close attention to shipping marks and
transport pictograms.
Careful packing, loading and transport arrangements are
required to prevent products from being damaged during
transport. Standard packaging includes a cardboard box, with
or without a wooden pallet base as needed. Special packaging
may include a wooden box. Packaging may use cardboard,
plastic wrap, foam, or paper as packing material. Filling
material may be a carton type or paper.
4
FCD VLEEIMFTOP-03 (EN/A4) June 2023
WARNING indicates that
or
severe personal injury,
Shipping marks display product and package dimensions and
weight (for further information see Packaging and Sending
Instructions, Form L 002). Packing guidelines for export
follow HPE standards. (Nonreturnable packaging may contain
up to 90% recyclable materials.)

7 Storage

Maximum storage time for control valves is
6 months.
The packing box begins to break down after
NOTICE
6 months. Leakage may develop.
Upon arrival on site, store the Valtek FlowTop on a solid base
in a cool, dry closed room. Until its installation, the valve
must be protected from the weather, dirt and other potentially
harmful influences.
Do not remove the protective covers from the body flanges of
the control valve or from the instrument ports of the actuator
and accessories until the valve is ready for installation at the
site.

8 Unpacking - Lifting

Hoisting and lifting are inherently danger-
ous activities and require safe rigging and
proper training to mitigate hazards. Use
standard industry safety practices, personal
protection, and warranted lifting devises.
Crushing hazard ! Arrange rigging
WARNING
to prevent tipping of the control
valve. Do not allow the valve assembly to rotate during re-
moval. Do not stand under suspended loads. Failure to do
so can cause serious personal injury and damage the valve
or nearby equipment.
Be aware that the center of gravity may be
NOTICE
above the lifting point. Do not allow the sling
to touch the stem, travel indicator or peripheral equipment.
Observe the maximum permitted working load limit.
Flowserve is not a transport and lifting company. It is the
responsibility of the persons commissioned on site to carry
out these tasks in accordance with good and relevant rigging
and lifting practices and in compliance with the currently ap-
plicable rules. The proposals presented are tried and tested
