Valtek FlowTop
13.3 Disassembly / reassembly instructions of the valve bonnet.
Standard Bonnet - VN
Bellows Seal Bonnet - VB # A
see page 32 - 33
Standard Bonnet - 0N
30
FCD VLEEIMFTOP-03 (EN/A4) June 2023
High Temperature Bonnet - VR
Bellows Seal Bonnet - VB # B
see page 33 - 34
Low Temperature Bonnet - OK
see page 37
see page 31
Insulating Bonnet - VI
see page 34 - 35
Insulating Bonnet - OI
see page 38 - 39
Heavy Duty Bonnet - SN
see page 42
Low Temperature Bonnet - VK
Insulating Bonnet - VT
see page 36
High Temperature Bonnet - KR
see page 40 - 41
