13.2 Disassembly / reassembly instructions of the valve body.
3-Flange - flanged
4-Flange - flanged
Top guided - see page 22 - 24
20
FCD VLEEIMFTOP-03 (EN/A4) June 2023
Angle - flanged
3-Way - mixing
see page 26 - 27
3-Flange - welded
see page 21 - 22
4-Flange - welded
Top and bottom guided - see page 24 - 26
3-Flange - flanged with heating jacket
Angle - welded
4-Flange - flanged with heating jacket
3-Way - distributing
see page 28 - 29
