Wall Mount Touchpanels
4 ¥ Wall Mount Touchpanels: TPS-12L/15L/17L
TPS-12L/15L/17L Specifications (continued)
SPECIFICATION
Connectors
NET One 4-pin 5 mm detachable terminal block for connection to
Cresnet
USB One USB port (reserved for future applications)
RS-232 One 6-pin RJ-11 female connector, bi-directional RS-232 serial
connection, touchscreen output to PC, telestrator, or serial mouse
connection
Headphones One 3.5 mm stereo TRS mini phone jack, output power 12 mW,
impedance 32 Ohms (nominal)
QM IN One RJ-45 QuickMedia input connector
VIDEO IN One RJ-45 CNX-PVID differential video input connector
AUDIO I/O One RJ-45 CNX-BIPAD balanced stereo audio input and
microphone output connector
LAN One 8-wire RJ-45 Ethernet port with link/activity LED indicators,
10BaseT/100BaseTX high-speed Ethernet, TCP/IP, UDP/IP, CIP,
DHCP, 802.3U compliant, full duplex, auto switching
Buttons Five illuminated pushbuttons, the leftmost button (SW1) is
recessed and is a hardware reset used to reboot the touchpanel,
the four other buttons are user programmable
Display
Type Active Matrix Color LCD
Aspect Ratio TPS-12L 4:3
TPS-15L 4:3
TPS-17L 15:9
Resolution TPS-12L 800 x 600
TPS-15L 1024 x 768
TPS-17L 1280 x 768
Brightness TPS-12L 400 nits
TPS-15L 400 nits
TPS-17L 450 nits
Contrast TPS-12L 300:1
TPS-15L 300:1
TPS-17L 400:1
Illumination Backlit fluorescent
Viewing Angle TPS-12L +/- 70 degrees horizontal, +45/-55 degrees vertical
TPS-15L +/- 85 degrees horizontal and vertical
TPS-17L +/- 88 degrees horizontal and vertical
Enclosure Metal enclosure with molded plastic bezel
CPU 32-bit Motorola Coldfire
Processing Speed 410 MIPS
Operating Environment Temperature: 41° to 113°F (5° to 45°C)
Humidity: 10% to 90% RH (non-condensing)
TPS-12L Dimensions Height: 11.80 in (29.98 cm)
Width: 13.61 in (34.57cm)
Depth: 3.81 in (9.68 cm)
Weight: 8.5 lbs (3.86 kg)
When used with RMK-12L, occupies eight rack spaces
Continued on the following page
®
Crestron Isys TPS-12L/15L/17L
DETAILS
Operations Guide – DOC. 6355
