System Reserved Joins (continued)
NUMBER FUNCTION
17235 Exit and Run Program
17236
17239 Test Pattern
17240 Display Eeprom
17261 Not Tpi Flag
17262 Display Ethernet
17263 Mode Touchout
17265 Touchout Action 0
17266 Touchout Action 1
17267 Touchout Action 2
17268 Touchout Action 3
17269 Touchout Action 4
17270 Touchout Action 5
17271 Touchout Action 6
17272 Touchout Action 7
17273 Touchout Action 8
17274 Touchout Action 9
17275 Touchout Action A
17276 Touchout Action B
17277 Touchout Action C
17278 Touchout Action D
17279 Touchout Action E
17280 Touchout Action F
17281 Touchout State Up
17282 Touchout State Dn
17283 Input Ts Off
17285 Selftest Running
17286 Setup Blank Page Press
17287 Setup Active
17200 Cresnet ID
17201 Lcd Brt
17203 Standby Timeout
17204 Touchout State A
17205 Touchout Destination A
17206 Touchout Channel A
17207 Touchout Analog Join A
17208 Touchout Analog Join Plus One A
17209 Touchout Format A
17210 Touchout State B
17211 Touchout Destination B
17212 Touchout Channel B
17213 Touchout Analog Join B
Continued on the following page
Wall Mount Touchpanels
INPUT
NO
Save NO
YES
YES
NO
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
NO
NO
NO
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
