Crestron Isys TPS-12L Operation Manual page 47

®
Crestron Isys TPS-12L/15L/17L
Operations Guide – DOC. 6355
Composite-1A Control Reserved Joins
NUMBER FUNCTION
19819 Composite-1A Brightness Up
19820 Composite-1A Brightness
19821 Composite-1A Contrast Up
19822 Composite-1A Contrast Down
19837 Composite-1A Saturation Up
19838 Composite-1A Saturation Down
19839 Composite-1A Hue Up
19840 Composite-1A Hue Down
19719 Composite-1A Brightness
19721 Composite-1A Contrast
19723 Composite-1A Saturation
19725 Composite-1A Hue
Composite-2A Control Reserved Joins
NUMBER FUNCTION
20119 Composite-2A Brightness Up
20120 Composite-2A Brightness
20121 Composite-2A Contrast Up
20122 Composite-2A Contrast Down
20137 Composite-2A Saturation Up
20138 Composite-2A Saturation Down
20139 Composite-2A Hue Up
20140 Composite-2A Hue Down
20019 Composite-2A Brightness
20021 Composite-2A Contrast
20023 Composite-2A Saturation
20025 Composite-2A Hue
YPbPr-1 Control Reserved Joins
NUMBER FUNCTION
20419 YPbPr-1 Brightness Up
20420 YPbPr-1 Brightness Down
20421 YPbPr-1 Contrast Up
20422 YPbPr-1 Contrast Down
20437 YPbPr-1 Saturation Up
20438 YPbPr-1 Saturation Down
20439 YPbPr-1 Hue Up
20440 YPbPr-1 Hue Down
20319 YPbPr-1 Brightness
20321 YPbPr-1 Contrast
20323 YPbPr-1 Saturation
20325 YPbPr-1 Hue
Continued on the following page
Wall Mount Touchpanels
INPUT
YES
YES
Down
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
INPUT
YES
YES
Down
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
INPUT
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
Wall Mount Touchpanels: TPS-12L/15L/17L ¥ 43
OUTPUT TYPE
YES DIGITAL
YES DIGITAL
YES DIGITAL
YES DIGITAL
YES DIGITAL
YES DIGITAL
YES DIGITAL
YES DIGITAL
YES ANALOG
YES ANALOG
YES ANALOG
YES ANALOG
OUTPUT TYPE
YES DIGITAL
YES DIGITAL
YES DIGITAL
YES DIGITAL
YES DIGITAL
YES DIGITAL
YES DIGITAL
YES DIGITAL
YES ANALOG
YES ANALOG
YES ANALOG
YES ANALOG
OUTPUT TYPE
YES DIGITAL
YES DIGITAL
YES DIGITAL
YES DIGITAL
YES DIGITAL
YES DIGITAL
YES DIGITAL
YES DIGITAL
YES ANALOG
YES ANALOG
YES ANALOG
YES ANALOG
