Crestron Isys TPS-12L/15L/17L
Crestron Isys
Touchpanels: TPS-12L/15L/17L

Introduction

Operations Guide – DOC. 6355
®
Wall Mount

Features and Functions

®
The Crestron Isys TPS-12L, TPS-15L and TPS-17L family of wall mount
touchpanels offer high brightness and contrast combined with a super wide viewing
angle to deliver crisp, detailed images under all conditions. For simplicity within this
guide, these touchpanels are referred to as TPS-12L/15L/17L, except where noted.
These touchpanels are QuickMedia™ compatible. The features and specifications
(except for screen size and resolution) for all three touchpanels are identical. The
TPS-12L/15L17L touchpanels are available with a variety of color bezels (ex. black
with silver accent, white with gray accent).
Functional Summary
•
12, 15, and 17 inch (widescreen) active matrix color displays
•
Screen resolutions: TPS-12L 800 x 600, TPS-15L 1024 x 768,
TPS-17L 1280 x 768
•
16.7 million colors, 24-bit graphics with 8-bit alpha channel
•
128 MB of DDR RAM, 32 MB of internal flash (expandable to
160 MB)
•
Built-in time-based correction for stable video and graphics
•
Supports composite, S-video, and component inputs in both NTSC and
PAL formats
•
Supports QuickMedia™ transport technology, which affords expanded
AV connectivity through a streamlined wiring solution
•
Supports Crestron Home
•
Full screen video capability
•
Up to 4,000 digital and analog signals; up to 999 serial signals
•
Built-in microphone and biamplified speaker system
•
Built-in audio amplifier, 5 W per channel
•
Stores and plays back WAV sound files
•
Stereo headphone jack
•
Stereo audio input and microphone output
•
10BaseT/100BaseTX high-speed Ethernet, 802.3U compliant, full
duplex, auto switching
•
Five backlit hard buttons (one reset and four programmable buttons)
•
Includes a TPMC-CH-IMC to facilitate A/V connections
Wall Mount Touchpanels
®
CAT5 balanced A/V connectivity
Wall Mount Touchpanels: TPS-12L/15L/17L ¥ 1
