Audio Setup Details
AUDIO MENU
CONTROLS
Master The volume of all audio types (WAV, line, and key click) is
affected by the Master Volume control. If the Master Volume
control is set to 100%, the volume for any type of audio is at
maximum. If the Master Volume is set to 0%, the value of all
audio types is overridden and the touchpanel is silent. If Master
Volume is a percentage (say 50%), then all audio types can only
achieve half their value.
Treble Adjusts the overall treble output with the UP▲ and
DOWN ▼buttons.
Bass Adjusts the overall bass output with the UP▲ and
DOWN ▼buttons.
Mute A separate mute button is provided for each of the six mixer
inputs and one for the master control.
Wave Adjusts the volume of the Wav file with the UP▲ and
DOWN ▼buttons. Click Play Test WAV File button to sample
and adjust the volume as a pre-loaded WAV file plays.
Line Adjusts line level audio with the UP▲ and DOWN ▼buttons.
QM (Prog) Adjusts the QM program audio level with the UP▲ and DOWN
▼buttons.
QM Mic 1 Adjusts the level of microphone 1 with the UP▲ and DOWN
▼buttons.
QM Mic 2 Adjusts the level of microphone 2 with the UP▲ and DOWN
▼buttons.
Key Click Adjusts the level of the key click sound with the UP▲ and
DOWN ▼buttons.
QM Link Status Indicates QM connectivity
Ethernet
Selection of the Ethernet button from the SETUP MENU displays details such as
the IP Address, Subnet Mask, Default Router, IP Table, etc. The settings can only be
viewed from this screen. The enable/disable Ethernet feature is provided on the
INTERFACE MENU. Ethernet settings are made through Crestron Toolbox. Refer
to page 51 for additional Ethernet setup details.
Video Menu
The touchpanel can display composite, S-video, and component video input from
one of the selected sources, from the TPMC-CH-IMC interface unit, a CNX-PVID,
or from the QM input connector in both NTSC and PAL formats. Select the Video
button from the SETUP MENU to display the video screen, shown in the following
illustration. You can select Video Auto Detect, QM Auto Detect, or choose one
particular input source.
Controls for BRIGHTNESS, CONTRAST, SATURATION, and HUE are
provided independently for each video source. Controls for PEAK, BOOST, QM
Preset and auto compensation (AC) are provided for QM video input.
The Restore Default Values button resets the controls to the factory settings. After
video parameters have been set, select the Return button to return to the SETUP
MENU.
Refer to the following graphic and table for additional information.
®
