Wall Mount Touchpanels
40 ¥ Wall Mount Touchpanels: TPS-12L/15L/17L
System Reserved Joins (continued)
NUMBER FUNCTION
17214 Touchout Analog Join Plus One B
17215 Touchout Format B
32768 Product Name Text Join
32769 Product Version Text Join
32770 Everything Else Text Join
Audio Reserved Joins
NUMBER FUNCTION
17300 All Audio On
17301 All Audio Off
17302 Key Click On
17303 Key Click Off
17304 Key Click Volume Up
17305 Key Click Volume Down
17306 Line On
17307 Line Off
17308 Line Volume Up
17309 Line Volume Down
17312 WAV On
17313 WAV Off
17314 WAV Volume Up
17315 WAV Volume Down
17320 Play Test WAV File
17321 Defaults
17322 Beep Short
17323 Beep Medium
17324 Beep Long
17325 Bass Up
17326 Bass Dn
17327 Treble Up
17328 Treble Dn
17329 All Audio Volume Up
17330 All Audio Volume Down
17349 Master Mute Button
17350 Keyclick Mute Button
17351 Line Mute Button
17352 Wave Mute Button
17300 Key Click Volume
17301 Line Volume
17302 WAV Volume
17305
17306 Treble
17307 All Audio Volume
