3.4 Plumbing

3.4.1 Plumbing overview

Chemical exposure hazard. Dispose of chemicals and wastes in accordance with local,
regional and national regulations.
Open the display panel to see the components of the analysis section. Refer to
Figure 6 Analysis section components
1 Plumbing diagram
2 Drain pinch valve
3 Sample pinch valve
4 Dosing cuvette
16 English
C A U T I O N
5 Cell for dump waste liquid
6 Air valve
7 Piston pump
8 Safety valve
Figure 6.
9 Digestion cuvette
10 Ceramic valve
11 Handle
