2.6 Product components

Make sure that all components have been received. Refer to
damaged, contact the manufacturer or a sales representative immediately.
Figure 2 Product components
1 Instrument
2 Brackets for wall mount (2x)
3 Screws for wall and table mount (12x)
4 Cable strain reliefs (4x)

Section 3 Installation

Multiple hazards. Only qualified personnel must conduct the tasks described in this
section of the document.
8 English
Figure
5 Plastic bottle cap (2x)
6 Glass bottle cap (2x)
7 Pharmed tube, ID 2.4 mm, OD 5.6 mm,
1.2 m (3.9 ft)
8 Plastic tube, ID 1.6 mm, OD 3.2 mm, 6 m
(19.7 ft)
W A R N I N G
2. If any items are missing or
