CYBEX Arc Trainer 770A Service Manual page 61

Install grips
must be on the bottom
Pull the black
Connect the red wire to the tab on the top grip. Verify connection is secure.
Connect the black wire to the tab on the bottom grip. Verify connection is secure.
Do not pinch heart wires or allow contacts to touch each other when installing grips.
Install the two screws securing the grips in place using a Phillips screwdriver.
grips.
Repeat steps for right side.
Install back cover
Install four screws securing back cover to console using a Phillips screwdriver.
Back
Cover
Screws (4)
Top Grip
Red heart rate wire
must be on the top
Black heart rate wire
Bottom Grip
Screws (2)
61
Cap
wire through
Do not over tighten
