CYBEX Arc Trainer 770A Service Manual page 47

Install linkage rods
Place linkage rod in correct position.
Place a drop of loctite on the SHCS and place another drop of loctite into the shaft (where the
SHCS will be tightened into).
Connect battery connector
Connect battery connector to control board.
Install controller cover
Place the controller cover into position.
Attach the screws securing the cover in place using a Phillips screwdriver.
Install access cover
Hold the access cover in place, do not pinch any cables.
Tighten the four screws securing the access cover using a Phillips screwdriver.
Test unit for proper operation
Plug the optional power cord into the power outlet.
Operate the unit at all levels to verify proper operation.
47
