Remove left shroud
Remove the eight screws securing left shroud using a Phillips screwdriver.
Remove left shroud.
Unplug incline motor cable
Loosen the top two screws and remove the bottom two screws using a phillips screwdriver.
Remove the controller cover.
Unplug incline motor cable from control board.
Cut wire tie using side cutters.
Cable
Tie
Control
Board
Screw
(8)
Left
Shroud
Top Screws
Incline
Motor
Cable
Controller
Cover
Bottom
Screws
54
