Endless Pools FASTLANE PRO Owner's Manual page 34

Fastlane Pro Swim Unit Installation
®
Section 9 DECK MOUNT FASTLANE PRO INSTALLATION
9.1 Loosely secure the hanger bracket to the hose cover tray with one of the provided 1/2" (12,7mm) stain-
D
Fig. 9.1
9.2 Carefully lay the assembled Fastlane Pro down on its front face. There are six pre-drilled holes in the
Fig. 9.2
33
less steel screws. Measure down from the top of the hanger bracket to the water line (this measurement
is called freeboard). Once the measurement has been taken, remove the hanger bracket from the tray
(Fig 9.1).
center of the top housing (between the protective hat channels). Align the top set of holes in the rear of
the housing with appropriate number hole in the hanger bracket (if the freeboard is 6" (15,2cm) then
align the #6 holes with the top holes in the housing). When the hanger bracket is positioned on the
housing, use the provided 3/4" (19mm) screws to attach (Fig 9.2).
