INSTALLATION MANUAL

Endless

™

Original Series Pools

WITH HYDRODRIVE™ TECHNOLOGY

Need help?

Do you have a question about the Original Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Endless Pools Original Series

Page 1 INSTALLATION MANUAL Endless ™ Original Series Pools WITH HYDRODRIVE™ TECHNOLOGY...
Page 2 NO DIVING DANGER: DIVING MAY RESULT IN SERIOUS INJURY OR DEATH. IMPORTANT SAFETY INSTRUCTIONS CONSIGNES DE SÉCURITÉ IMPORTANTES READ, FOLLOW, AND UNDERSTAND ALL INSTRUCTIONS LIRE, SUIVRE ET COMPRENDRE TOUTES LES INSTRUCTIONS Manufacturers Safety Instructions DANGER: BEFORE INSTALLING OR USING THIS PRODUCT, READ, FOLLOW, AND UNDERSTAND ALL SAFETY INFORMATION.
Page 3 Other Important Safety Instructions WARNING: To reduce the risk of injury, do not permit children to use this product unless they are closely supervised by an adult at all times. AVERTISSEMENT: Pour réduire le risque de blessure, ne permettez pas aux enfants d’utiliser ce produit à moins qu’ils ne soient surveillés de près en tout temp WARNING: To reduce the risk of injury:...
Page 4 DANGER: RISK OF ACCIDENTAL DROWNING: Extreme caution must be exercised to prevent unauthorized access by children. To avoid accidents, ensure that children cannot use this spa unless they are supervised by an adult at all times. DANGER: RISQUE DE NOYADE ACCIDENTELLE: Une extrême prudence doit être exercée pour empêcher tout accès non autorisé...
Page 5 WARNING: THE USE OF ALCOHOL OR DRUGS CAN GREATLY INCREASE THE RISK OF FATAL HYPERTHERMIA IN HOT TUBS AND SPAS. AVERTISSEMENT: LA CONSOMMATION D’ALCOOL OU DE DROGUE AUGMENTE CONSIDÉRABLEMENT LES RISQUES D’HYPERTHERMIE MORTELLE DANS UNE CUVE DE RELAXATION. WARNING: PREGNANT OR POSSIBLY PREGNANT WOMEN SHOULD CONSULT A PHYSICIAN BEFORE USING A SPA OR HOT TUB.
Page 6 Loose cover/grates shall be reattached before bathers are allowed to use the pool. Suction Outlet Fitting Assembly (SOFA) User Maintenance Instructions Field Modifications Any field modification made to the SOFA not authorized by Endless Pools installation instructions shall void the suction outlet fitting assembly certification. Configuration Modifications No modification shall be made to a SOFA structure or flow path unless the new configuration has been certified as a new SOFA.
Page 7 Installation Instruction Booklet Information The entire Endless™ Pools system is ETL listed, Ref. #2001779 and conforms to UL Standard #1563. Individually, all electrical components of the Endless pool are UL and/or CSA approved. As defined by the International Residential Code (IRC), the Endless pool is considered an aboveground or an in-ground pool depending on the installation.
Page 8 1. Pool Arrival & Inspection Pool Arrival & Inspection Drainage should be provided at the pool. It is ideal to install a floor drain in the area just outside of the front The Endless™ pool arrives in three packages: a skid of pool pool panel, but not directly under the panel or pool itself.
Page 9 6. Optional Insulation (by others) Optional Insulation (by others) 6-1/2" (16,5cm) To conserve heat and reduce operating costs we strongly recommend that the Endless™ pool be insulated with rigid foam. Simple 1-1/2” (38mm) thick rigid foam insulation boards are usually adequate and are available from any building supply store.
Page 10 7. Liner Hanger Liner Hanger Bend the four 8’ (2,44m) lengths of Liner Hanger that have been notched, so that they will fit into each The standard Liner Hanger (A) installs around the perimeter corner. Measure to ensure the middle corner piece of the pool panel enclosure.
Page 11 8. Optional Liner Hangers Optional Liner Hangers OPTIONAL BULLNOSE COPING SYSTEM Typically used when the pool is installed fully in-ground, 1-1/2" 2-1/8" (38mm) the Bullnose Coping System (A) allows the installer to finish (54mm) with concrete and/or tile (B) right up to the water’s edge. 1/2"...
Page 12 11. Liner Underlayment Liner Underlayment If it is possible, finish the rest of the pool area, especially the ceiling over the pool, before proceeding. This will help ensure that the liner is not damaged, and also keep the pool water, skimmer, and filter free of construction debris. Vacuum the pool floor carefully, and make sure there are no sharp bumps that may damage the liner.
Page 13 13. Thru-Wall Connections (Part 1) Thru-Wall Connections (Part 1) Shoes should be removed for the liner installation and all future work in the pool to avoid damaging the liner. This section should only be followed if the optional Spread the liner in the pool enclosure. Locate the vertical Hydraulic Treadmill or Hydrotherapy Jets were ordered.
Page 14 OPTIONAL HYDROTHERAPY JETS: FACEPLATES OPTIONAL HYDROTHERAPY JETS: JET AND SUCTION COVERS BULKHEAD FITTINGS AND JET BODIES The Faceplates (A) for the Jet Suctions should now be The four holes for the Jet Bulkheads can be cut in the installed and holes for the Thru-Wall fittings can be liner and the Jet Bulkhead Fittings (A) and Jet Bodies (B) cut in the liner (Fig.
Page 15 Install the Water Quality System Suction and Return Thru- Remove the Locknut (F) and Cork Gasket (E) from each Wall Assemblies. Thru-Wall Fitting (C), shown in Fig. 18, that is pre-attached to each Hydraulic Hose. Feed the hoses through the wall. Insert the Suction Thru-Wall Assembly (C) through the liner The hose with the red tape wrapped around the fitting (A) and pool wall (B) making sure the Black Gaskets (D) are...
Page 16 LED WALL LIGHTS Attach the Circulation Pump (A) to the bottom of the pre-plumbed assembly from the previous step. Make sure The Light Lens should be installed at this time. that the Pump Union O-Ring (B) is seated properly prior to installing the pump (Fig.
Page 17 The next step is best accomplished with a helper. Align Attach the Pre-Plumbed Return Union and Valve Assembly the Heater-Controller (A) with the Pre-Plumbed Pump to (A) to the Water Quality System Return Thru-Wall Heater Assembly (B). Make sure a T-Gasket (C) is installed Assembly (B).
Page 18 17. Skimmer-Filter Installation Skimmer-Filter Installation Glue the Pre-Plumbed Gecko Outlet to Return Assembly (A) onto the Flex Pipe (B) that was cut in the previous step. Remove the two screws at the rear right of the Propulsion Make sure to apply PVC primer and cement to the faces of Housing.
Page 19 Attach the PVC fittings to the bottom of the skimmer Connect the Heavy Duty Flex Hose (A) to the Insert Elbow. assembly as shown in Figure 31. Glue the Bushing Reducer Secure the hose to the elbow with the Hose Clamp (C) (A) into the “OUT”...
Page 20 19. Keypad Installation Keypad Installation Attach the Skimmer Shroud Body (A) to the Skimmer Mounting Bracket (B) using the provided 1” (25mm) screws The Water Quality System Keypad (Fig. 37) should now be (C). Attach the Skimmer Shroud Lid (D) to the Angle at the installed.
Page 21 20. Hydraulic Power Unit Hydraulic Power Unit Remove the caps on the ports of the power unit. Attach the Low-Pressure Hose (A), hose with the red tape, to The Hydraulic Power Unit should be placed on flat and level the fitting attached to the Fill Cap (B). Attach the High surface.
Page 22 21. Electrical Wiring - 60Hz Electrical Wiring - 60Hz (U.S. and countries with a similar power supply) (U.S. and countries with a similar power supply) ALL ELECTRICAL CONNECTIONS SHOULD BE MADE BY A LICENSED ELECTRICIAN. NOTE: The following instructions are intended for Single Phase equipment. If Three Phase equipment was ordered, refer to the Three Phase Equipment Supplemental Guide at this time.
Page 23 HEATER-CONTROLLER WIRING - ORIGINAL, PERFORMANCE, AND DUAL PROPULSION POOL Locate the electrical whip provided in the Hydraulic/Electrical Connections Kit. Remove one of the unused knockouts at the bottom of the Hydraulic Power Unit Controller enclosure and secure the whip end to the open knockout. Connect the black wire (Line 1) to terminal block T3.
Page 24 HEATER-CONTROLLER WIRING - ELITE POOL Locate the electrical whip provided in the Hydraulic/Electrical Connections Kit. Remove one of the unused knockouts at the bottom of the Hydraulic Power Unit Controller enclosure and secure the whip end to the open knockout. Connect the black wire (Line 1) to terminal block T3.
Page 25 HEATER-CONTROLLER ACCESSORY WIRING Each high voltage accessory wired into the Heater-Controller has an electrical cord with connectors that correspond with the quick connect terminals OR the AMP connectors inside the Heater-Controller. Route the cords from the accessories to the controller. The cords for the Keypad, LED Lights, and optional Remote Pool Monitoring should be routed through the strain relief channel at the bottom of the controller.
Page 26 HEATER-CONTROLLER CABLE CLAMP SYSTEM Reinsert the clamp in its original position, pressing down on either side of the cord (Fig. 46). Remove the empty clamp from the enclosure (Fig. 43). Fig. 46 Fig. 43 Once all clamps are installed, reinstall the front cover Open the clamp and place the wire inside.
Page 27 22. Electrical Wiring - 50Hz Electrical Wiring - 50Hz (U.K. and countries with a similar power supply) (U.K. and countries with a similar power supply) ALL ELECTRICAL CONNECTIONS SHOULD BE MADE BY A LICENSED ELECTRICIAN. NOTE: The following instructions are intended for Single Phase equipment. If Three Phase equipment was ordered, refer to the Three Phase Equipment Supplemental Guide at this time.
Page 28 HEATER-CONTROLLER WIRING - ORIGINAL, PERFORMANCE, AND DUAL PROPULSION POOL Locate the electrical whip provided in the Hydraulic/Electrical Connections Kit. Remove one of the unused knockouts at the bottom of the Hydraulic Power Unit Controller enclosure and secure the whip end to the open knockout. Connect the black wire (Line 1) to terminal block T3.
Page 29 HEATER-CONTROLLER WIRING - ELITE POOL Locate the electrical whip provided in the Hydraulic/Electrical Connections Kit. Remove one of the unused knockouts at the bottom of the Hydraulic Power Unit Controller enclosure and secure the whip end to the open knockout. Connect the black wire (Line 1) to terminal block T3.
Page 30 HEATER-CONTROLLER ACCESSORY WIRING Power Jumper Wires (PJ1 & PJ2) MUST be removed and connected to the appropriate terminals. Each high voltage accessory wired into the Heater-Controller has an electrical cord with connectors that correspond with the quick connect terminals OR the AMP connectors inside the Heater-Controller. Route the cords from the accessories to the controller. The cords for the Keypad, LED Lights, and optional Remote Pool Monitoring should be routed through the strain relief channel at the bottom of the controller.
Page 31 HEATER-CONTROLLER CABLE CLAMP SYSTEM Reinsert the clamp in its original position, pressing down on either side of the cord (Fig. 51). Remove the empty clamp from the enclosure (Fig. 48). Fig. 51 Fig. 48 Once all clamps are installed, reinstall the front cover Open the clamp and place the wire inside.
Page 32 23. Bonding & Grounding Bonding & Grounding All of the electrical components supplied by Endless™ Pools are UL or CSA approved and must be installed in accordance with local electric codes by a licensed local electrician. Bonding and Grounding are an important part of that process. All electrical components have bonding lugs and should be bonded together and to the steel pool panels.
Page 33 24. Isolation Cover Isolation Cover Included with the Water Quality System is an Isolation Cover designed to protect the equipment from water intrusion. This cover MUST be installed. Failure to install the Isolation Cover voids the warranty. Position the Isolation Cover (A) over the Heater-Controller Mounting Board (B). The tabs of the cover nest into the slots at the top of the mounting board.
Page 34 IMPORTANT NOTE: Vinyl liners may develop wrinkles over time if the pool temperature is set above 90ºF (32˚C). Low-Level Endless Pools Model without Ascent Skirting Corner Lights Max Temp Original, Performance, Elite Endless Pool with standard electric Heater-Controller 92˚F (33˚C) Original, Performance, Elite, Dual Propulsion Endless Pool with optional Gas Heater 92˚F (33˚C)
Page 35 REMOVING AIR FROM WATER QUALITY SYSTEM is a common error code that may appear on the keypad during the initial start up of the pool as a result of air trapped in the plumbing lines. Shut off the power to the pool equipment. 2.
Page 36 NATURE 2 INSTALLATION Remove the Nature 2 from it’s packaging. Attach the Handle (B) to the bottom of the Cartridge (A). Loop the Sanitation of your pool water is partly accomplished provided Zip Tie (D) around the Handle and above the by placing one Nature 2 Continuous Silver Ion sanitizer Fins (C) and then interlock the strap end into its locking into the pool filter.
Page 37 26. User’s Guides User’s Guides Optional Solar Blanket Roll Up System Endless™ Pools offers a Solar Blanket for all Endless Two User’s Guides will be provided with your pool; the pool sizes if the Retractable Security Cover has not been Water Quality System User’s Guide and the Hydrodrive™...
Page 38 EXERCISE STEP AQUABIKE Bring step aerobics to your Endless™ Pool! This adjustable The Aquabike is more effective than indoor cycling for step was constructed especially for water exercise. weight loss and heart health, with added bonuses; by pedaling underwater, you get a lower-impact workout The non-skid top and weighted, rubber-edged bottom that’s gentle on your joints and delivers 360°...
Page 39 more, all with incredible sound. The Duo attaches securely The step color is dictated by your choice of benches. If you to goggle straps, resting on the cheekbones and does not select platinum acrylic benches you will receive a platinum acrylic corner step.
Page 40 Endless™ Pools 1601 Dutton Mill Rd Aston, PA 19014-2931 D40073_en 1124 (800) 910-2714 ©2024 Wellness Marketing Corporation www.myendlesspool.com...
