Summary of Contents for Endless Pools STREAMLINE

  • Page 1 STREAMLINE USER’S GUIDE...

  • Page 2: Table Of Contents

    Winterizing Your StreamLine Pool . . . . . . . . . . . . . . . . . .
  • Page 4 RISK OF ELECTRICAL SHOCK A GROUND FAULT CIRCUIT INTERRUPTER (GFCI) OR RESIDUAL CURRENT DEVICE (RCD) is required for this product. The Ground Fault Circuit Interrupter (GFCI) or Residual Current Device (RCD) is NOT provided with this product. One must be sourced locally and installed into the panel box by a licensed electrician when making the electrical connections to the spa equipment.
  • Page 5 TO REDUCE THE RISK OF DROWNING Prolonged immersion in high temperature water can cause hyperthermia. Hyperthermia occurs when the internal temperature of the body is several degrees higher than the normal 98.6°F (37°C). The symptoms of hyperthermia include dizziness, lethargy, drowsiness, and fainting. The effects of hy- perthermia include: 1.

  • Page 6: Buttons And Indicators

    1. Streamline Pool Keypad Display Buttons and Indicators The keypad display is the command center for the Streamline propulsion system and water quality system . The keypad activates the pump that drives the propulsion system and also controls the temperature and maintenance features of the pool . The following is an overview of the keypad functions .

  • Page 7: Water Chemistry

    Overview A water chemistry start-up kit, including test kit, has been provided with the StreamLine Pool. This kit should be sufficient to get the pool properly balanced and ready to swim . Over the course of the pool’s life, additional balancing chemicals will be required . Endless Pools can only ship these aftermarket chemicals in the continental United States .
  • Page 8 Many customers are sold a stabilized chlorine product for use in where well water is to be the water source, strong consideration their indoor StreamLine Pool . Endless Pools would not recom- should be given to having water tanked in . Well water often has mend this practice, as Clorox bleach is ideal for this setting .

  • Page 9: Pool Equipment And Startup Operation

    bleach (any brand is fine as long as it does not have an added scent Notes: to it) to an indoor pool. If you have an outdoor pool, add the appro- It is very important to keep the pH within range . If the level is priate amount of granules out of the bag of “stabilized”...
  • Page 10 4 times daily, for 60 seconds. pluming . DO NOT completely unthread the union . Bleed air to the The in .xe is a heater controller used by Endless Pools to control point where you start to see water escaping from the union . Once the following features: the air has been bled out, retighten the union (Fig.

  • Page 11: How To Control The Swim Current

    File: E182156 Fig . 3 CSA No . 22 .2 - 218 .1-M89 . If you are new to the Streamline Pool, first verify that the second- TUV Standards: ary speed control valve is closed (turned fully clockwise). Next, turn on the swim current using the keypad . By pressing the key 1 EN/IEC 60335 - 2 - 60 button once the pump will turn on at low speed .

  • Page 12: Streamline Pool Maintenance

    Reinstall the filter cartridge and then place the floating skimmer cage over top the cartridge . Fig. 5 5. Streamline Pool Maintenance Attach the handle to the main body of the Nature 2 cartridge by aligning the hole at the bottom of the handle to the nipple that’s Daily: attached to the main body of the cartridge (Fig.

  • Page 13: Draining Your Streamline Pool

    3-5ppm, but don’t swim until FC falls below 3ppm). Shocking screwdriver and clean as necessary . Reinstall grill before restart- the pool should burn off the combined chlorine . ing machine . The StreamLine Pool must not be operated with this front grill removed . Every two weeks: •...

  • Page 14: Winterizing Your Streamline Pool

    7. Winterizing the Streamline Pool 8. Water Quality Error Codes A StreamLine Pool may be used year round, even in colder cli- mates . If you will not be using the pool during the winter in an An internal hardware error has been detected in area where freezing is a problem, special consideration must be in .xe .

  • Page 15: Quality System Troubleshooting

    9. Propulsion System and Water Quality System Troubleshooting Symptom Possible Cause Solution 1.) Tripped breaker 1.) Reset breaker No power to controller 2.) Disconnect turned off 2.) Turn disconnect to ON position 3.) Improperly wired controller 3.) Verify wiring of controller 1.) No power to controller 1.) See above diagnosis No Keypad Display...
  • Page 16 9. Propulsion System and Water Quality System Troubleshooting Symptom Possible Cause Solution 1.) 25 amp fuse blown inside the 1.) Check for continuity on the fuse and Pump Propulsion System heater controller replace if necessary Wont Turn On 2.) No power to pump receptacle 2.) 25 amp fuse may be blown inside heater on the heater controller controller .

  • Page 17: Water Chemistry Test Log

    TEST LOG...
