P5/8/08
Page 1 of 26
TM
FASTLANE POOL
OWNER'S MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the FASTLANE POOL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Endless Pools FASTLANE POOL

Summary of Contents for Endless Pools FASTLANE POOL

  • Page 1 P5/8/08 Page 1 of 26 FASTLANE POOL OWNER’S MANUAL...
  • Page 2 Page 2 of 26 RECEIVING YOUR FASTLANE POOL Your Fastlane Pool is shipped by common carrier and contains the following 13 packages: 1. (8) Top 130 cm Straight Tubes, wider (Part B for the pool assembly) 2. Electric Heater (optional), Skimmer, Owner’s Manual and Plumbing & Start-Up Kit 3.

  • Page 3: Ground Preparation

    Page 3 of 26 GROUND PREPARATION The surface the Fastlane Pool is to be assembled on must be firm and level. The Fastlane Pool must be installed as level as possible, within 2”- 3” of level (from the highest point to the lowest point of the pool).
  • Page 4 (G) Struts 1. Unfold and spread out liner (A) on the prepared area. Keep in mind your “swim direction” when positioning the liner. When the Fastlane Pool is fully assembled, you will be swimming towards the skimmer, so plan accordingly 2.
  • Page 5 P5/8/08 Page 5 of 26 4. Connect the (B) and the (C) tubes together. NOTE: The (C) tube (shorter, wider tube) is always the last tube on the right when facing the pool wall. (Refer to Diagram #2: Wider Straight Tube Layout) DIAGRAM #2: WIDER STRAIGHT TUBE LAYOUT 5.
  • Page 6 P5/8/08 Page 6 of 26 6. Insert and connect the top corner tubes (D). It may be helpful to insert both ends of corner tube (D) into the corresponding liner sleeves, followed by pulling back and connecting one side at a time to top rail. 7.
  • Page 7 P5/8/08 Page 7 of 26 FASTLANE SWIM UNIT ASSEMBLY 1. Verify that all items have arrived. NOTE: If using a power drill, do NOT over tighten the screws, as this will strip the thread in the PVC of the Fastlane Swim Unit.
  • Page 8 P5/8/08 Page 8 of 26 7. Run the hydraulic hose up the back of the Swim Unit Housing so that the PVC hat channel will cover the hose. Firmly secure, but do NOT over tighten, the eight (8) stainless screws per hat channel. Repeat for the second hose. 8.
  • Page 9 13. Re-install the throat that was removed previously in Step 4. 14. Place the Swim Unit on the ground and roll it close to the Fastlane Pool location for installation. Be careful not to tip over the Swim Unit, as it is front-heavy.
  • Page 10 P5/8/08 Page 10 of 26 16. The hydraulic hoses can be simply left hanging over the top of the pool wall and run back to the Power Unit. Tie the bonding wire to one of the end struts (G) located near the Fastlane Swim Unit to bond the Swim Unit to the pool.

  • Page 11: Electrical Requirements

    Although the pump will be running continuously, the heater will run only when the Fastlane is not in use. Fastlane Pool Package with optional 55,000 BTU Gas or Propane Heaters The Hydraulic Power Unit (HPU) is shipped with two whips coming from the EP1 Controller mounted on the HPU.
  • Page 12 " Fittings and Piping Endless Pools, Inc. has provided a sufficient quantity of PVC fittings and piping for most installations. There are extra fittings provided. Additional fittings and pipe can be purchased locally at most hardware stores. Be sure to use “pressure” fittings rather than standard drain fittings.
  • Page 13 QTY =9 QTY = 2 QTY = 2 QTY = 1 QTY = 2 QTY = 2 NOTE: Pictures are not drawn to scale. Parts can be ordered from Endless Pools, Inc., a local hardware store or a plumbing supply store.
  • Page 14 (#10) to (#8) now sticking out of the wall of the Fastlane Pool. Tighten with a large pair of channel locks. Make sure the nut is very snug but do not over-tighten, as this may crack your fitting.
  • Page 15 (#10) to (#8) now sticking out of the wall of the Fastlane Pool. Tighten with a large pair of channel locks. Make sure the nut is very snug but do not over-tighten, as this may crack your fitting.
  • Page 16 P5/8/08 Page 16 of 26 The Equipment Please refer to the drawings and photographs on the following pages for suggested plumbing layouts. While it is important to follow the general layout, the equipment can be laid out to suit the specific needs of your site. Please call your Endless Pool design professional if you need guidance on equipment location.
  • Page 17 P5/8/08 Page 17 of 26 Optional Gas Heater/Water Quality System Optional Gas Heater/ Water Quality System Plumbing Mounting and Equipment Mount the equipment to the PVC board using the hardware supplied with the circulating pump. The two (2) 3/8” bolts are used to fasten the circulating pump using the threaded inserts already located in the base.
  • Page 18 36” minimum vertical clearance is required to remove the filter cartridge. As mentioned previously, suitable drainage must be provided at both the Fastlane Pool and the water quality system. All electric components must be located, installed and bonded by a licensed local electrician in accordance with applicable codes.
  • Page 19 P5/8/08 Page 19 of 26 FASTLANE POWER UNIT ASSEMBLY Placement Considerations The Power Unit should be elevated from the ground and placed on a flat surface. If placing the Power Unit outside, it is recommended the Outdoor Power Unit with Weather Guard be purchased to protect it against the everyday elements.
  • Page 20 Unit off and add the additional oil. NOTE: Do not run the Power Unit without the fill cap in place. 8. Be sure to bond the Fastlane Pool and the hydraulic Power Unit by connecting a #8 or larger copper bonding wire to the bonding lug located ?????? and running that wire (typically along with the hydraulic hoses) back to the hydraulic Power Unit.
  • Page 21 Your Fastlane remote control operates by radio waves. Should the hydraulic Power Unit be placed too far away from the Fastlane Pool, your remote control may not operate efficiently. To operate your Fastlane more effectively, please install the antenna remotely with the enclosed kit.
  • Page 22 Adding 1/2 cup of Clorox a day will add about 0.5 ppm of free chlorine to a Fastlane Pool. How quickly that chlorine is consumed will depend upon the water temperature, swimmer load and the amount of direct sunlight the pool receives.
  • Page 23 If you have any questions, please contact our Customer Service Department at 1- " 800-910-2714. If you do choose to winterize, you must drain the Fastlane Pool below all wall fittings, " Swim Unit and view ports. When storing your pool, thoroughly clean and dry the liner and carefully roll it up.
  • Page 24 NO DIVING into the Fastlane Pool. Please keep children supervised at ALL times! Endless Pools is an industry leader in customer service. Should you have any questions about or need assistance with your Fastlane Pool, please call our Customer Service Department at 1-800-910-2714.
  • Page 25 P5/8/08 Page 25 of 26 FASTLANE POOL START-UP KIT Additional water quality and swimming products are always available at www.myendlesspools.com...
  • Page 26 All labor costs for removal and re-installation of the defective part and all freight charges shall be paid by the purchaser and will not be reimbursed by Endless Pools, Inc. This warranty is expressly in lieu of all other warranties expressed or implied including the warranties of...
