Summary of Contents for Endless Pools FastLane

Page 1 FASTLANE ® By Endless Pools, Inc. OWNER’S MANUAL Wall Mount Installation...
Page 2 The Fastlane can fit in virtually any swimming pool. For optimal water flow, we recommend that you allow at least 12 feet between the wall on which the Fastlane is installed and the opposing wall in line with the Swim Unit. The Fastlane has six discrete inlet grills with more than 5 square feet of opening to eliminate any entrapment hazards.
Page 3 If the pool being constructed is gunite or concrete, please follow the instructions below. Parcel 1 includes the Wall Mount Fastlane bracket for concrete or gunite pools. Two (2) 24' 6" rolls of 1" poly pipe are shipped separately. The standard bracket is comprised of the following components (refer to Photo 4.A.1): •...
Page 4 Wall Mount Bracket will sit along the pool’s intended waterline.) The rods penetrate a few inches into the finished pool and will be used to hang the Wall Mount Fastlane. These rods must be tied back to the rebar of the bond beam in the pool and, once encased in concrete, will serve as a suitable hanger.
Page 5 If installing the provided 1" poly pipe (standard installation), the Wall Mount Fastlane ships with two (2) 24' 6" rolls of 1" poly pipe. From the rear side of the pool, feed each 1" poly pipe into the liquid-tite fit- tings and tighten the cord grip on the 1"...
Page 6 Remove the star thru-wall fittings and threaded rod pieces with hex coupling nut attachments from the 1/8"- thick, grey PVC template. Position the PVC template where the Fastlane will attach to the pool wall and align the bottom of the template with the expected water level in the pool (which will typically be located at the centerline of the skimmer) as shown in Figure 4.4.
Page 7 Remove the liquid-tite fittings, bonding lug assembly, and threaded rod pieces from the 3/8"-thick, grey PVC bracket plate which serves as a template. Position the PVC template where the Fastlane will attach to the pool wall and align the bottom of the PVC template with the expected water level in the pool (which will typically be located at the centerline of the skimmer).
Page 8 F a s t l a n e S w i m U n i t I n s t a l l a t i o n ® SEE VIEW A 3/8" PVC TEMPLATE POOL SKIMMER CENTERLINE OF SKIMMER WATERLINE OF POOL DRILL 1 5/8"...
Page 9 It is at the junction box where a step up to 1/2" run hose occurs. The hydraulic hose from the Fastlane Swim Unit to the junction box is 3/8" and the run hose from the junction box...
Page 10 • Roll of anti-corrosion tape If installing the optional junction box with the 1" poly pipe: • The Fastlane ships with two (2) 24' 6" rolls of 1" poly pipe. Do NOT cut down the length of this 1" poly pipe.
Page 11 ELECTRICAL REQUIREMENTS FOR UK AND OTHER INTERNATIONAL COUNTRIES The unique design of the Fastlane facilitates sales to UK and international customers. The Fastlane is shipped in kit form for easy assembly and installation into any new conventional pool following the detailed instructions provided.
Page 12 On the collapsed cardboard, pushing the grill into the ‘L ’ channel on lay the Fastlane Swim Unit on its front. the inside middle right of the housing. Attach the supplied wheels by sliding 9.11...
Page 13 10.1 the wall mount bracket and 1-1/2" below the two (2) mounting rods. Using two people, one on each side of the Fastlane Swim Unit, place one hand on the side of the 10.2 grab rail and the other hand on the back of the Swim Unit. Carefully, lift the Swim Unit and gently lower it into the pool using the wheels as a guide along the pool wall.
Page 14 Because the underside of your Fastlane will be sucking in water, it may occasionally become necessary to clean the grill of any debris or leaves that may have been in your pool when the Fastlane was in operation. With the Fastlane unit turned off, this is very easy to accomplish while in the pool.
Page 15 F a s t l a n e M a i n t e n a n c e ® Cover 1/2'' Screw Hydraulic Hose Upper Grill Grab Rail Green Hose Clamp Self-locking 3/4'' Screw Housing 1'' Screw 1/2'' Screw Wheel Red-threaded Screw Base...
