ENDLESS POOLS
FASTLANE
SPORT
®
®
INSTALL ATION AND OPERATIONS MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FASTLANE SPORT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Endless Pools FASTLANE SPORT

Summary of Contents for Endless Pools FASTLANE SPORT

  • Page 1 ENDLESS POOLS FASTLANE SPORT ® ® INSTALL ATION AND OPERATIONS MANUAL...
  • Page 2 WARNING: Before each use, examine the unit for damage or signs of wear. Do not use the product if found in this condition. Contact Endless Pools Customer Service. WARNING: NEVER operate the unit without reading and completely understanding the results of any operational change you request from the controller.
  • Page 3 Endless Pools Fastlane Sport Installation ® Other Important Safety Instructions WARNING: To reduce the risk of injury, do not permit children to use this product unless they are closely supervised at all times. AVERTISSEMENT: Pour réduire le risque de blessure, ne permettez pas aux enfants d'utiliser ce produit à...
  • Page 4 Endless Pools Fastlane Sport Installation ® DANGER: RISK OF ACCIDENTAL DROWNING: Extreme caution must be exercised to prevent unauthorized access by children. To avoid accidents, ensure that children cannot use this spa unless they are supervised at all times. DANGER: RISQUE DE NOYADE ACCIDENTELLE: Une extrême prudence doit être exercée pour...
  • Page 5 Endless Pools Fastlane Sport Installation ® WARNING: DO NOT USE DRUGS OR ALCOHOL BEFORE OR DURING THE USE OF A SPA OR HOT TUB TO AVOID UNCONSCIOUSNESS AND POSSIBLE DROWNING. AVERTISSEMENT: POUR ÉVITER L'ÉVANOUISSEMENT ET LA NOYADE ÉVENTUELLE, NE PRENDRE NI DROGUE NI ALCOOL AVANT D'UTILISER UNE CUVE DE RELAXATION NI QUAND ON S'Y TROUVE.
  • Page 6 Loose cover/grates shall be reattached before bathers are allowed to use the unit. Suction Outlet Fitting User Maintenance Instructions Field Modifications: Any field modification made to the suction outlet fitting not authorized by Endless Pools installation instructions shall void the suction outlet fitting assembly certification. Configuration Modifications: No modification shall be made to a suction outlet fitting structure or flow path unless the new configura- tion has been certified as a new suction outlet fitting assembly.

  • Page 7: Table Of Contents

    Fastlane Sport Information The Endless Pools Fastlane Sport has been tested and certified by MET Labs, listing # E114906, and is evaluated to UL 1563 and CSA 22.2 No. 218.1-13. The Fastlane Sport is considered a “field installed accessory” through UL 1563. Individually, all electrical components of the Fastlane Sport are UL and or CSA approved.

  • Page 8: Receiving Fastlane Sport

    Choosing A Location For The Fastlane Sport The Fastlane Sport can fit into virtually any swimming pool. For optimal water flow, we recommend that there is a minimum of 12' (3,7m) between the wall in which the swim unit is installed and the opposing wall. It’s also recommended that the wa- ter depth where the swim unit is to be installed is at least 39"...

  • Page 9: Unboxing Fastlane Sport

    Sport Installation ® Section 3: UNBOXING FASTLANE SPORT 1. Cut the plastic bands around the box and remove the lid (Fig. 2). 2. Remove the protective cardboard from the box (Fig. 3). 3. Slide the box skirting up and away from the swim unit (Fig. 4).

  • Page 10: Fastlane Sport Installation

    Lifting Point Fig. 6 Section 4: FASTLANE SPORT INSTALLATION Included in the Fastlane Sport shipment is an installation kit containing all parts required to install the unit. The Fastlane Sport Installation Kit includes the following: QTY DESCRIPTION PART # Wall Standoff...
  • Page 11 Endless Pools Fastlane Sport Installation ® 1. If the pool coping extends past the inside pool wall, measure the distance (X) between the edge of the coping (coping overhang) and inside pool wall (Fig. 7). Pool Coping Coping Overhang Inside Pool Wall Fig.
  • Page 12 Endless Pools Fastlane Sport Installation ® 3. With a minimum of two people, one person on each side of the swim unit, carefully lift the unit at the recommended lifting points and lower the unit into the pool in the desired mounting location along the pool wall (Fig. 9).
  • Page 13 Endless Pools Fastlane Sport Installation ® 4. Once the unit is in the desired mounting location along the pool wall, remove the control box from the deck plate by removing the screws. Mark the magnet hole onto the pool deck using a marker (Fig. 11).
  • Page 14 Endless Pools Fastlane Sport Installation ® 6. With a minimum of two people, carefully lift the unit at the recommended lifting points and reposition it along the wall of the pool to expose the holes marked onto the pool deck.
  • Page 15 Endless Pools Fastlane Sport Installation ® 8.2 Two wrenches are required to set the anchor in the mounting hole. Use one wrench to hold the bolt stationary and the other to tighten the jam nut clockwise (Fig. 15). Tightening the jam nut will expand the anchor, setting it in the concrete, to prevent it from spinning in the mounting hole.
  • Page 16 Endless Pools Fastlane Sport Installation ® 9. Use the provided hardware to assemble the magnet as shown in Figure 17. Tighten jam nut #1 to hold the magnet to the head of the screw. Loosely attach jam nut #2 and the washer.
  • Page 17 Endless Pools Fastlane Sport Installation ® 11. With a minimum of two people, carefully lift the unit at the recommended lifting points and position the unit in the mounting location. Align the edges of the deck plate with the lines marked onto the pool deck making sure the holes in the deck plate align with the holes drilled into the pool deck.

  • Page 18: Housing Adjustment

    Endless Pools Fastlane Sport Installation ® Housing Adjustment Locate the pins installed on each side of the housing. With two people, one person on each side of the swim unit, remove the pins from the adjustment bracket. Adjust the height of the housing so that the top of the housing is at the same level or just below the pool’s waterline.

  • Page 19: Electrical Installation

    Endless Pools Fastlane® Sport Installation Section 4: ELECTRICAL INSTALLATION All of the electrical equipment supplied by Endless Pools is UL or CSA approved. WARNING: All electrical connections should be made by a licensed electrician in accordance with all applicable nation- al and local code.

  • Page 20: Fastlane Sport Electrical Wiring Connections - 60Hz (Us)

    Endless Pools Fastlane Sport Installation ® Fastlane Sport Electrical Wiring Connections – 60Hz (US) GFCI FUSE, 1 AMP SAFETY RELAY RESET LINE 1 TRANSFORMER SWITCH NEUTRAL GROUND MOTOR LIGHT RELAY AIR SWITCH HIGH VOLTAGE G W B CONTROL BOX COVER...

  • Page 21: Bonding

    To be compatible with chemically treated water, Endless Pools uses a stainless steel wire (pre-attached during the manufac- turing of the unit) to connect the metal components inside the Fastlane Sport. The Fastlane Sport MUST then be bonded to the pool’s bonding grid using a #8 solid copper wire. The copper wire is not supplied by Endless Pools.

  • Page 22: Pre-Start Up Procedure

    PRE START UP PROCEDURE Priming Pump Before starting the Fastlane Sport for the first time, the pump MUST be primed. DO NOT run the pump dry. Running the pump dry can result in a failure of the mechanical seal. NOTE: It’s important to maintain proper water level in the pool to ensure the pump remains primed.

  • Page 23: Product Installation Information

    Endless Pools Fastlane Sport Installation ® 3. With the tube still attached, close the air purge valve by turning it fully clockwise. Remove the tube from the air purge valve. 4. Reinstall the lid of the housing using the (4) #8-32 x 1/2" (13mm) Phillips pan head screws (Fig. 30).

  • Page 24: Initial Start Up & Operation

    Endless Pools Fastlane Sport Installation ® Section 6: INITIAL START UP & OPERATION Electrical Start Up 1. Once all electrical connections have been made and the housing lid has been reinstalled, supply power to the system by turning on the breaker.

  • Page 25: Using The Fastlane Sport

    ® Using the Fastlane Sport Turn ON and OFF the Fastlane Sport by pressing the pneumatic ON/OFF button locatated on the right side of the swim unit (Fig. 32). Adjust the speed of the swim current by rotating the speed control valve located on the right side of the swim unit (Fig.

  • Page 26: Maintenance & Service Instructions

    MAINTENANCE & SERVICE INSTRUCTIONS Water Quality Maintenance It’s important for the long-term operation of unit that the pool water be properly balanced per Endless Pools recommenda- tions. Pools using salt chlorine generators require additional maintenance. Water chemistry MUST be closely monitored.

  • Page 27: Winterizing

    1. Turn off power to the Fastlane Sport. Remove the lid of the control box assembly by removing the screws (Fig. 35).
  • Page 28 Endless Pools Fastlane Sport Installation ® 2. Disconnect the electrical connections for the pump motor and safety circuit. Loosen the liquid-tight fittings to remove the electrical cords. Remove the liquid-tight fittings from the control box enclosure (Fig. 36). Lock Nut...
  • Page 29 Endless Pools Fastlane Sport Installation ® 4. Re-install the lid of the control box assembly (Fig. 38). Fig. 38 5. Remove the lid of housing by removing the screws around the perimeter of the lid (Fig. 39). Disconnect the copper bond- ing wire that’s attached to the pump motor.
  • Page 30 Endless Pools Fastlane Sport Installation ® 6. With one person stabilizing the unit (to prevent it from falling into the pool) remove the mounting hardware that secures the swim unit to the pool deck (Fig. 40). Hex Head Machine Screw...
  • Page 31 Endless Pools Fastlane Sport Installation ® 8. Open the air purge valve located at the 12 o’clock position on the pump housing (Fig. 42). Allow the water to drain out of the pump housing. Pump Housing Air Purge Valve Fig. 42 9.

  • Page 32: Suction Outlet Fitting Service Instructions

    Endless Pools Fastlane Sport Installation ® 10. Remove the magnet from the pool deck and store with the swim unit for the winter months (Fig. 44). Magnet Hole in pool deck for magnet Fig. 44 11. To prevent debris from getting inside the holes in pool deck during the winter months, thread the provided hex head bolts (used for setting the anchors in the concrete pool deck) into the holes (Fig.
  • Page 33 Endless Pools Fastlane® Sport Installation The suction outlet MUST be repaired or replaced if it’s missing, loose, dented, cracked, or broken. The fasteners and corresponding receptacles MUST be replaced or repaired if damaged. #10 x 1” (25mm) 316 Stainless Steel Phillips Truss Head Screws.
  • Page 34 4.4 Use fasteners provided by the manufacturer to reinstall suction outlet grill. 5. Re-install the front skin, side skins, diverter end cap, On/Off button tube, and lid following steps 1-2 in reverse order. Call the Endless Pools: 800-910-2714 (US) • 0800-520-0196 (UK) • 610-497-4538 (Direct)
  • Page 35 Endless Pools Fastlane Sport Installation ®...
  • Page 36 Endless Pools • 1601 Dutton Mill Rd • Aston, PA 19014-2931 D30012 0420 800-910-2714 US • 610-497-8693 fax • www.myendlesspool.com © Copyright 2020 Wellness Marketing Corporation...
