Module Configuration

Addr. Bits Description
[7:4] MPSoC type
0x08
[3:0] MPSoC device speed grade
[7:6] Temperature range
[5] Power grade
0x09
[4:3] Gigabit Ethernet port count
[2] RTC equipped
[1:0] Reserved
[7:2] Reserved
0x0A
[1:0] USB 2.0 port count
[7:4] DDR4 ECC RAM ﴾PS﴿ size ﴾GB﴿
0x0B
[3:0] DDR4 RAM ﴾PL﴿ size ﴾GB﴿
[7:4] eMMC flash size ﴾GB﴿
0x0C
[3:0] QSPI flash memory size ﴾MB﴿
Table 42: Module Configuration
The memory sizes are defined as Resolution 2
DRAM = 0: none
DRAM = 1: 1 GB
DRAM = 2: 2 GB
DRAM = 3: 4 GB
Table 43 shows the available MPSoC types.
Value MPSoC Device Type
0 XCZU6EG
1 XCZU9EG
2 XCZU15EG
Table 43: MPSoC Device Types
Table 44 shows the available temperature ranges.
D‐0000‐443‐001
Min. Value Max. Value
0 2
1 3
0 2
0 ﴾Normal﴿ 1 ﴾Low power﴿
0 2
0 1
‐ ‐
‐ ‐
0 2
0 ﴾0 GB﴿ 4 ﴾8 GB﴿
0 ﴾0 MB﴿ 3 ﴾4 GB﴿
0 ﴾0 GB﴿ 5 ﴾16 GB﴿
0 ﴾0 MB﴿ 7 ﴾64 MB﴿
﴾Value‐1﴿
, for example:
54 / 61
Comment
See MPSoC type ta‐
ble ﴾Table 43﴿
See temperature
range table ﴾Table 44﴿
Resolution = 1 GB
Resolution = 1 GB
Resolution = 1 GB
Resolution = 1 MB
