Petalinux BSP

The Enclustra Petalinux BSPs enable the user to quickly set up a Petalinux project and to run Linux on the
Enclustra SoC module or system board.
The documentation [18] describes the build process in detail and allows a user without Petalinux knowl‐
edge to build and run the desired design on the target hardware.
1.4

Accessories

1.4.1

Enclustra Heat Sink

For Mercury modules an Enclustra heat sink is available for purchase along with the product. Refer to
Section 2.10.6 for further information on the available cooling options.
1.4.2

Mercury+ PE1 Base Board

The Mercury+ PE1 [13] is a versatile PCIe® x4 base board equipped with a multitude of I/O interfaces
for use with the Mercury/Mercury+ family of FPGA and SoC modules, providing a head start for building
custom FPGA and SoC based hardware systems.
It is compatible with a multitude of FMC boards from different suppliers to use in data acquisition systems,
motor control, display and camera interfaces, software defined radio and more. The board is equally well
suited for rapid prototyping and for building FPGA systems without designing custom hardware.
The available features depend on the Mercury module type and on the selected base board variant.
Tip
The pinout assignments ﴾pin types and I/O voltage levels﴿ on the module connectors B and C affects
the FMC interfaces. The compatibility of the Mercury+ XU7 SoC module with the Mercury+ PE1 base
board is therefore limited. Compare the FMC card pinout in detail with the Enclustra Mercury Master
Pinout and with the module and base board schematic.
1.4.3

Mercury+ PE3 Base Board

The Mercury+ PE3 [15] is a versatile PCIe® x8 base board equipped with a multitude of I/O interfaces
for use with the Mercury/Mercury+ family of FPGA and SoC modules, providing a head start for building
custom FPGA and SoC based hardware systems.
This high performance base board provides a versatile set of I/O connectivity options, specialized for
high‐speed communication and video applications, including SFP+, QSFP+, HDMI, USB Type‐C and Fire‐
fly. The board is equally well suited for rapid prototyping and for building FPGA systems without design‐
ing custom hardware.
The available features depend on the Mercury module type and on the selected base board variant.
1.4.4

Mercury+ ST1 Base Board

The Mercury+ ST1 board [14] is a compact, low‐cost base board equipped with a multitude of I/O inter‐
faces for use with the Mercury/Mercury+ family of FPGA and SoC modules.
It provides a versatile set of I/O connectivity options, specialized for video applications, including Dis‐
playPort, HDMI, MIPI, and SFP+. The board is equally well suited for rapid prototyping and for building
FPGA systems without designing custom hardware.
The available features depend on the Mercury module type and on the selected base board variant.
