On‐board clock generation is based on a 33.33 MHz crystal oscillator and a 100 MHz LVDS oscillator pro‐
viding a clock for the PL and a reference clock for the MGT GTR transceivers. In addition to this, another
27 MHz oscillator delivers a reference clock for the MGT GTR transceivers.
The module's internal supply voltages are generated from a single input supply of 5 to 15 V DC. Some
of these voltages are available on the Mercury module connectors to supply circuits on the base board.
Five LEDs are connected to the MPSoC pins for status signaling.
2.2

Module Configuration and Product Models

Table 1 describes the available standard module configurations. The product model indicates the module
type and main features. Figure
are available. Contact Enclustra for more information.
Product Model
ME‐XU7‐6EG‐1I‐D11E
ME‐XU7‐9EG‐2I‐D12E
ME‐XU7‐15EG‐2I‐D12E
Table 1: Standard Module Configurations
Figure 2: Product Model Fields
For the first revision modules or early access modules, the product model may not respect entirely this
naming convention. Contact Enclustra for more information.
2.3 EN‐Numbers and Product Models
Every product is uniquely labeled, showing the EN‐number and serial number. An example is presented
in Figure 3.
D‐0000‐443‐001
2 describes the fields within the product model. Custom configurations
MPSoC
XCZU6EG‐1FFVC900I
XCZU9EG‐2FFVC900I
XCZU15EG‐2FFVC900I
13 /
DDR4 ECC DDR4
SDRAM ﴾PS﴿ SDRAM ﴾PL﴿
2 GB 1 GB
4 GB 2 GB
4 GB 2 GB
61
Temperature
Range
‐40 to +85 C
‐40 to +85 C
‐40 to +85 C
