Internal Web Page

This section provides procedures for accessing and using the SW USB Pro internal web page. Topics in this
section include:
•

Accessing the Web Page

• Web Page Overview
The internal web page displays information about the SW USB Pro and provides basic configuration options. For
more detailed configuration, use SIS commands (see
or PCS (see the SW USB Pro Help File).
Accessing the Web Page
To access the internal web page:
1. Connect the switcher to a LAN or WAN using the rear panel LAN connector (see
NOTE: If the Ethernet connection to the switcher is unstable, try turning off the proxy server in the web
browser.
On a connected PC, open a web browser.
NOTE: The internal web page does not support compatibility mode in Microsoft Internet Explorer®.
Enter the IP address of the device in the browser Address field.
NOTE: The default IP address is 192.168.254.254.
2. Press the <Enter> key on the keyboard. The switcher checks if the device is password‑protected and performs
one of the following:
•
If the device is not password‑protected, the web page opens.
•
If the device is password‑protected, enter a user name (user or admin) in the User Name field and the
password in the Password field when prompted.
NOTE: The factory configured passwords for all accounts on this device have been set to the device
serial number. In the event of a complete system reset, the passwords convert to the default, which is
extron.
3. Click the OK button.
Remote Configuration and Control
SW USB Pro Series • Remote Configuration and Control
starting on page 16),
LAN Connector
on page 6).
