Extron electronics SW USB Pro Series User Manual page 5

Conventions Used in this Guide
Notifications
The following notifications are used in this guide:
CAUTION:
ATTENTION : Risque de blessure mineure.
ATTENTION:
•
Risk of property damage.
• Risque de dommages matériels.
NOTE: A note draws attention to important information.
Software Commands
Commands are written in the fonts shown here:
^AR Merge Scene, 0p1 scene 1,1 ^B 51 ^W^C.0
[01] R 0004 00300 00400 00800 00600 [02] 35 [17] [03]
*X1&* X2)* X2#*
E X!
NOTE: For commands and examples of computer or device responses used in this guide, the character "0" is
the number zero and "O" is the capital letter "o."
Computer responses and directory paths that do not have variables are written in the font shown here:
Reply from 208.132.180.48: bytes=32 times=2ms TTL=32
C:\Program Files\Extron
Variables are written in italics as shown here:
ping xxx.xxx.xxx.xxx —t
SOH R Data STX Command ETB ETX
Selectable items, such as menu names, menu options, buttons, tabs, and field names are written in the font
shown here:
From the
File
Click the
OK
Specifications Availability
Product specifications are available on the Extron website, www.extron.com.
Extron Glossary of Terms
Risk of minor personal injury.
X2! CE}
menu, select .
New
button.
A glossary of terms is available at https://www.extron.com/technology/glossary.aspx
