FOX3 Matrix Series • Setup Guide (Continued)

Accessing the Internal Web Page

Access the FOX3 Matrix internal web page as follows:
1. Connect the FOX3 Matrix to a LAN or WAN using the rear panel RJ-45 LAN port on the standard FOX3 Matrix (see figure 2,
C ) or the front panel USB config port (see figure 7,
NOTE: If connected to the FOX3 Matrix through the IPCP Pro Matrix Q xi control card, use the AV LAN port (see
IPCP Pro Matrix Q xi Control Card
2.
Open a web browser on a connected PC.
NOTE: Compatible web browsers are Microsoft Edge
3. Enter the FOX3 Matrix IP address in the browser Address field.
NOTES:
• If the local system administrators have not changed the value, the factory specified default for the LAN or WAN
connection is 192.168.254.254.
The default for the USB connection is 203.0.113.22 (this IP address cannot be changed).
•
4.
Press the <Enter> key on the keyboard.
5. The FOX3 Matrix is password protected. Enter user or admin in the Username field and the password in the Password field
when prompted (see figure 14).
NOTE: The factory configured passwords for all accounts on this device have been set to the device serial number. In
the event of a complete system reset, the passwords convert to the default. The default password is extron for the
admin and user.
Figure 14.
Network Password Prompt
6. Click the Sign in button. The internal web page opens (see
12
A ).
on page 5). DO NOT use the LAN port.
, Mozilla Firefox
® ®
figure 15
on page 13).
, Google Chrome™, and Apple
®
Safari .
® ®
