Application Diagrams

The following diagrams show examples of how an SW USB Pro Series switcher can be connected.
HDMI
USB
Laptop
Extron
SW2 USB Pro
SuperSpeed
USB Switcher
Figure 2. Connection Diagram for an SW2 USB Pro Switcher
PC 1
HDMI
PC 2
HDMI
PC 3
HDMI
PC 4
HDMI
Figure 3. Connection Diagram for an SW4 USB Pro Switcher
