- Page 1 User Guide HDMI Switchers SW HDMI Series Two and Four Input HDMI Switchers 68-1317-01 Rev. A 02 12...
- Page 2 Safety Instructions • English Warning Power sources • This equipment should be operated only from the power source indicated on the product. This This symbol is intended to alert the user of important operating and mainte- equipment is intended to be used with a main power system with a grounded (neutral) conductor. The third nance (servicing) instructions in the literature provided with the equipment.
- Page 3 FCC Class A Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation.
-
Page 4: Conventions Used In This Guide
Selectable items, such as menu names, menu options, buttons, tabs, and field names are written in the font shown here: From the menu, select File Click the button. Copyright © 2012 Extron Electronics. All rights reserved. Trademarks All trademarks mentioned in this guide are the properties of their respective owners. -
Page 5: Table Of Contents
Contents Introduction Remote Communication and Control ............1 ..... 19 About this Guide ..........1 Using Simple Instruction Set (SIS) Commands ..19 About the SW HDMI Series Switchers ....1 Host-to-switcher Communications ....19 Features .............. 1 Switcher-initiated Messages ......19 Application Diagram ........... - Page 6 SW HDMI Series • Contents...
-
Page 7: Introduction
In this guide, the term “SW HDMI Series” refers to both the SW2 HDMI and the SW4 HDMI switchers. “Switcher” and “SW HDMI” are used interchangeably to refer to any single unit. About the SW HDMI Series Switchers The Extron SW HDMI Series are two and four input, one output, High-definition Multimedia Interface (HDMI) switchers. - Page 8 • Remote configuration and control — The switcher can be configured via an RS-232 or USB connection via SIS commands (see “Using Simple Instruction Set (SIS) Commands” in the “Remote Communication and Control” section). • EDID Minder — A proprietary EDID (Extended Display Identification Data) management process from Extron, the EDID Minder manages the EDID between a digital display device and one or more input sources.
-
Page 9: Application Diagram
Laptop Blu-ray Player DSS Receiver Figure 1. Application Diagram for an SW4 HDMI Switcher NOTE: HDCP compliant sources require HDCP compliant displays (see the user manual of the source or display device for information on its HDCP compliance). SW HDMI Series • Introduction... -
Page 10: Installation
Installation This section describes the installation and setup of the SW HDMI Series switchers. Topics include: Installation Overview • • Rear Panel Features Wiring the Power Connector (Optional) • • Wiring for RS-232 Control • Connecting to the USB Port Enabling Auto-input Switching •... -
Page 11: Rear Panel Features
RS-232 AUTO Tx Rx Figure 3. SW4 HDMI Rear Panel Power connector — Plug the provided external 12 VDC, 1 A power supply into this 2-pole, 3.5 mm captive screw connector. Video input connectors — Connect HDMI video input sources to these Type A female single-link HDMI connectors. -
Page 12: Wiring The Power Connector (Optional)
Remote and auto-input switching connector — This 5-pole, 3.5 mm captive screw connector (labeled “Remote”) can be used for RS-232 communication with the switcher, including firmware updates, and to enable auto-input switching. To enable RS-232 control, connect the Tx (transmit), Rx (receive) and G (ground) •... -
Page 13: Wiring For Rs-232 Control
To verify the power cord polarity before connecting the plug, connect the power supply with no load and check the output with a voltmeter. Use the supplied tie-wrap to strap the power cord to the extended tail of the connector. The figure below shows how to wire the connector. -
Page 14: Connecting To The Usb Port
INPUTS OUTPUT AUTO SIGNAL SWITCH HDCP CONFIG SW4 HDMI HDMI SWITCHER Computer SW HDMI Front Panel Figure 6. USB Port Connection If this is the first time you have connected an SW HDMI to this USB port on your computer, the Found New Hardware Wizard opens. On the first screen, specify... - Page 15 Select the radio button if you want your computer to Yes, this time only • connect to Windows Update only this one time. Select if you want the computer Yes, now and every time I connect a device • to automatically connect to Windows Update to search the web every time the switcher is connected to this USB port.
-
Page 16: Enabling Auto-Input Switching
+5 V signal should be present only when the input source is powered on. However, some sources may also provide this signal while in standby mode. Figure 9 shows an SW4 HDMI with a jumper connecting pins 4 and 5 to enable auto-input switching. - 2 3 Figure 9. -
Page 17: Operation
CONFIG SW4 HDMI HDMI SWITCHER Figure 11. SW4 HDMI Front Panel Auto Switch LED — This LED lights when auto-input switching is in effect (see “Enabling Auto-input Switching” in the “Installation” section for the procedure to set up automatic input selection). - Page 18 Input Selection buttons and LEDs — Press these buttons to select inputs 1 and 2 or 1 through 4, depending on your model. The LED at the right of each button lights when the corresponding input is selected. These buttons are disabled if auto-input switching is in effect;...
-
Page 19: Operations
Operations Powering on the Switcher To power on the SW HDMI: Connect all input and output devices to the rear panel connectors on the switcher (see “Rear Panel Features” on page 5 for the rear panel connections). Power on the display. Plug the power supply into the 2-pole captive screw power connector on the rear panel. -
Page 20: Using The Optional Ir 102 Remote Control
30 feet (9 m) away (see figure 12). INPUTS INPUTS OUTPUT AUTO SIGNAL SWITCH HDCP CONFIG SW4 HDMI HDMI SWITCHER SW HDMI Series Switcher 30’ Maximum Universal Remote IR 102 Remote Control Figure 12. Area for Remote Signal Reception... -
Page 21: Locking And Unlocking The Front Panel (Executive Mode)
Locking and Unlocking the Front Panel (Executive Mode) Front panel lock mode disables all front panel controls, locking out users from those functions (RS-232, USB, and IR control remain available). Putting the switcher in lock mode enhances security by protecting against inappropriate or accidental changes to settings. If a front panel button is pressed during lock mode, all front panel LEDs blink once. - Page 22 User-assigned EDID mode In this mode, you can select an EDID file that is stored on the switcher at the factory. The selected EDID is stored at the inputs and is not overwritten; the switcher does not automatically obtain EDID information from the display. You may want to use this mode if there is a problem with automatic communication of the EDID information from the attached display, and you want to ensure that the correct information is stored on the inputs.
- Page 23 EDID table EDIDs listed in this table are arranged according to video format: DVI or HDMI. Within each format grouping, they are listed by rate type: PC or HDTV. Within each rate type grouping, the EDIDs are listed in order of resolution. SW HDMI Series •...
- Page 24 Footnotes for the EDID table The following footnotes apply to the EDID table on the previous page: Rate Type • PC: These are primarily VESA standard computer rates, based on the most commonly used native resolutions. They are designed to be used with computer sources. •...
-
Page 25: Remote Communication And Control
No response is required from the host. The following switcher-initiated message is displayed: (C) Copyright 20nn, Extron Electronics HDMI Switcher Series, Vn.nn, 60-641-nn The switcher sends the copyright message when it first powers on. V is the firmware version number;... -
Page 26: Error Responses
Error Responses If the switcher is unable to execute a command it receives because the command is invalid or contains invalid parameters, the switcher returns an error response to the host. The following error response codes can be sent: – Invalid input channel number (out of range) –... -
Page 27: Command And Response Table For Sis Commands
Command and Response Table for SIS Commands ASCII Command Response Command Additional Description (Host to Unit) (Unit to Host) Input Selection Select input • All Select input = input number: 0 through the highest number of inputs on the switcher (2 or 4). - Page 28 0 = Automatic (no EDID selected) Example: V4 • F2 • Vmt0 • Amt0 On an SW4 HDMI, input 4 is selected, EDID 2 (1024x768 @ 60 Hz) is selected, and neither the video nor the embedded audio is muted.
-
Page 29: Updating Firmware Using Firmware Loader
Updating Firmware Using Firmware Loader Updates to the SW HDMI Series firmware are made available periodically via the Extron website. You can find out what version of firmware is currently loaded on your switcher by entering the SIS Q command via the RS-232 or USB interface (see “Using Simple Instruction Set (SIS) Commands”on page 19 for the procedure for entering SIS... -
Page 30: Loading The Firmware To The Switcher
Open the Firmware Loader via your desktop menu by making the following Start selections: Start > All Programs > Extron Electronics > Firmware Loader > Firmware Loader The Firmware Loader window opens with the Add Device window displayed in front of it. - Page 31 Depending on the connection method that you selected, additional options appear. Make the appropriate selections for your connection method. RS-232: Select the appropriate options from the menus Com Port Baud Rate • (this information is provided by your system administrator). USB: Only the option is available on the Extron USB Device_0...
- Page 32 On the Add Device window, the path to the new firmware file is displayed in the Path field. Figure 19. Path to the New Firmware File on the Add Device Window If this is the only device to which you are uploading firmware, click .
- Page 33 If you want to remove a device from the Devices section, do the following: Click on the names of the devices to be deleted, to highlight them. Select from the menu. Remove Selected Device(s) Edit On the Remove Device(s) window, select or deselect any devices on the list as desired, then click Remove To remove all devices, select...
-
Page 34: Reference Information
Reference Information This section reference information for the SW HDMI Series switchers. Topics that are covered include: Specifications • • Part Numbers Mounting the SW HDMI • Specifications Video Maximum data rate ......6.75 Gbps (2.25 Gbps per color) Maximum pixel clock ...... 165 MHz Resolution ........ - Page 35 Power consumption Device ........2.8 watts, 12 VDC Device and power supply ..3.8 watts, 12 VDC Temperature/humidity ....Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing Cooling ..........
-
Page 36: Part Numbers
Included Parts These items are included with the SW HDMI Series switcher: Included Parts Part Numbers SW2 HDMI 60-841-01 SW4 HDMI 60-841-02 12 VDC, 1 A external power supply 70-055-01 IEC power cord 3.5 mm 2-pole captive screw power plug 100-454-01 (2) 3.5 mm 5-pole captive screw connectors... -
Page 37: Mounting The Sw Hdmi
Mounting the SW HDMI The SW HDMI switcher can be set on a table, mounted on a rack shelf, or mounted under a desk, podium, or table. Tabletop Use Four self-adhesive rubber feet are included with the SW HDMI. For tabletop use, attach one foot at each corner on the bottom of the unit, and place the switcher where desired. - Page 38 9.5-inch rack 1U Universal Rack Shelf 1/2 Rack Width Front False Faceplate Front false faceplate uses 2 screws. (2) 4-40 x 3/16" Use 2 mounting holes on Screws opposite corners. Figure 23. Mounting an SW HDMI Switcher on a Standard 9.5-inch Deep Rack Shelf Back of the rack mounting The SW HDMI can also be mounted vertically to the front or rear rack supports, using the...
-
Page 39: Furniture Mounting
Mount the switcher to the rack support, using the two included rack screws. M AT R IX IE S VI D IT C H ER D IO Figure 25. Mounting an SW HDMI Switcher to a Back of the Rack Support Furniture Mounting To mount an SW HDMI switcher under a desk, table, or podium, use the optional MBU 123 Mini Under-Desk Mounting Kit (part number 70-212-01) as follows:... - Page 40 Drill 3/32 inch (2 mm) diameter pilot holes, 1/4 inch (6.3 mm) deep, into the mounting surface at the marked screw locations. Insert #8 wood screws into the four pilot holes. Tighten each screw into the mounting surface until slightly less than 1/4 inch of the screw head protrudes. Align the centers of the slots in the brackets with the mounting screws and place the unit against the surface, with the screw heads through the bracket slots.
-
Page 41: Extron Warranty
Extron Electronics makes no further warranties either expressed or implied with respect to the product and its quality, performance, merchantability, or fitness for any particular use. In no event will Extron Electronics be liable for direct, indirect, or consequential damages resulting from any defect in this product even if Extron Electronics has been advised of such damage.
