Operation

This section provides a description of the SW USB Pro front panel features and describes the procedures for
performing the functions that are accessed from the front panel. The following topics are covered:
•

Front Panel Features

•
Powering on the System
• Selecting an Input (Host)
•
Locking and Unlocking the Front Panel (Executive Mode)
• Emulations
•
Resetting
• Troubleshooting
• Updating Firmware
Front Panel Features
A A A B B B C C C
EXEC AUTO
MODE SWITCH
CONFIG
Figure 10. Front Panel — SW2 USB Pro
A A A B B B C C C
EXEC AUTO
MODE SWITCH
CONFIG
Figure 11. Front Panel — SW4 USB Pro
Exec Mode LED
A
Auto Switch LED
B
USB Config port
C
Exec Mode LED — This green LED lights when front panel lock mode (executive mode) has been selected,
A
and that input selections cannot be made from the front panel (see
(Executive Mode)
on page 19) or PCS (see the SW USB Pro Help File).
Auto Switch LED — This LED lights when auto-switching is enabled (see
B
up automatic input selection).
D D D
INPUTS
1 2
D D D
INPUTS
1 2 3
Input Selection buttons and LEDs
D
Host LEDs
E
Device Status LEDs
F
on page 13). This can be configured via SIS (see
E E E
STATUS
HOSTS
1 2 3 4
DEVICES
SW2 USB PRO
USB SWITCHER
STATUS
HOSTS
4
1 2 3 4
DEVICES
SW4 USB PRO
USB SWITCHER
Locking and Unlocking the Front Panel
Front Panel Lockout (Executive Mode)
SW USB Pro Series • Operation
F F F
E E E
F F F
Auto Switching
on page 12 to set
