Example 5 (Pr.78 = d01): Execute one cycle through the PLC program
Freq.
60Hz
50Hz
40Hz
Fwd.
15Hz
P82
10Hz
P17
0Hz
P81
Rev.
P18
20Hz
30Hz
Application Note:
Changing the value of Jog parameters 15 and 16 will interrupt PLC program execution.
PLC program execution will not be interrupted when and other parameter values are
changed.
Pr.79 PLC Forward/Reverse
Factory Setting 00
Units None
Settings 00 - 127
This parameter controls the direction of motion for the multi-speed parameters 17 to 23.
P20
P21
P19
P84 P85
P83
61
® ® ® ® ®
VLT MICRO
P17=10Hz P42=16 P81=1.0
P18=20Hz P45=09 P82=1.2
P19=40Hz P46=10 P83=1.5
P20=60Hz P78=01 P84=1.5
P21=50Hz P79=34 P85=0.8
P22=30Hz
P23=15Hz
Note: Operation time is 10-times
P87
P23
P22
P86
P86=1.7
P87=1.7
by setting value.
P17
Time
