Pr.40 Multi-Function Input Terminals (M3)
Factory Setting 06
Units None
Settings 03 - 20
Pr.41 Multi-Function Input Terminals (M4)
Factory Setting 07
Units None
Settings 03 - 20
Pr.42 Multi-Function Input Terminals (M5)
Factory Setting 08
Units None
Settings 03 - 20
Parameter - Function List:
Value M2-M5 Function
0 0 No Function
01 Output OFF (N.O.)
02 Output OFF (N.C.)
03 External Fault (Normally Open)
04 External Fault (Normally Closed)
05 External Reset
06 Multi-Step Speed Control 1
07 Multi-Step Speed Control 2
08 Multi-Step Speed Control 3
09 Jog Frequency
10 Accel./Decel. Speed Inhibit Control
Value 01,02 (output off) is enabled when running
Value M2-M5 Function
11 1st-2nd Accel./Decel. Time Select
12 External Base Block
13
External Base Block
14
Increase Output Frequency Control
15 Decrease Output Frequency Control
16 Run PLC Program
17 Pause PLC Program
18 Counter Trigger
19 Counter Reset
20 No Operation
21
RESET (N.C.)
38
® ® ® ® ®
VLT
MICRO
(Normally Closed)
(Normally Open)
