Example 1 (Pr.78 = d01): Execute one cycle through the PLC program
Freq.
60Hz
50Hz
40Hz
30Hz
P18
20Hz
15Hz
P17
10Hz
0Hz
P81
P82
Program
operation
command.
Program
operation
indication.
Step operation
indication.
Program
operation
completed
indication.
Example 2 (Pr.78 = d02): Continuously execute program cycles
Freq.
60Hz
50Hz
40Hz
30Hz
P18
20Hz
15Hz
P17
10Hz
0Hz
P81
P82
Step operation
indication.
Program
operation
completed
indication.
P20
P21
P19
P83
P84
P85
P20
P21
P19
P83
P84
P85
59
® ® ® ® ®
VLT
MICRO
P17=10Hz P42=16 P81=1.0
P18=20Hz P45=09 P82=1.2
P19=40Hz P46=10 P83=1.5
P20=60Hz P78=01 P84=1.5
P21=50Hz P79=00 P85=1.7
P22=30Hz
P23=15Hz
Note: Operation time is 10-times
P22
by setting value.
P23
P86
P87
P17=10Hz P42=16 P81=1.0
P18=20Hz P45=09 P82=1.2
P19=40Hz P46=10 P83=1.5
P20=60Hz P78=02 P84=1.5
P21=50Hz P79=00 P85=0.8
P22=30Hz
P86=1.7
P23=15Hz
P87=1.7
Note: Operation time is 10-times
P22
by setting value.
P23
P17
P86
P87
P81
P86=1.7
P87=1.7
Time
P18
Time
P82
