PN-CD701
LCD MONITOR
OPERATION MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Sharp PN-CD701

Summary of Contents for Sharp PN-CD701

  • Page 1 PN-CD701 LCD MONITOR OPERATION MANUAL...
  • Page 2 IMPORTANT: To aid reporting in case of loss or theft, please record the Model No.: product’s model and serial numbers in the space provided. The numbers are located in the rear of the product. Serial No.: U.S.A. ONLY...

  • Page 3: Important Information

    IMPORTANT INFORMATION WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. The lightning flash with arrowhead symbol, within CAUTION a triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” RISK OF ELECTRIC within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric...

  • Page 4: Dear Sharp Customer

    DEAR SHARP CUSTOMER Thank you for your purchase of a SHARP LCD product. To ensure safety and many years of trouble-free operation of your product, please read the Safety Precautions carefully before using this product. SAFETY PRECAUTIONS Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly handled.
  • Page 5 SAFETY PRECAUTIONS (Continued) 19. Batteries — Incorrect use of batteries may cause the batteries to burst or ignite. A leaky battery may corrode the equipment, dirty your hands or spoil your clothing. In order to avoid these problems, make sure to observe the precautions below: • Use the specified batteries only.

  • Page 6: Tips And Safety Instructions

    - Never rub or tap the monitor with hard objects. so could result in electric shock. - Please understand that SHARP CORPORATION bears no - Unplug the power cord if it is not used for a long time. responsibility for errors made during use by the customer or...

  • Page 7: Mounting Precautions

    • Since the monitor is heavy, consult your dealer before installing, removing or moving the monitor. • Mounting the monitor on the wall requires special expertise and the work must be performed by an authorized SHARP dealer. You should never attempt to perform any of this work yourself. Our company will bear no responsibility for accidents or injuries caused by improper mounting or mishandling.

  • Page 8: Table Of Contents

    Specifications ..............31 Remote control operation range .........15 Turning Power On/Off ............16 Intellectual Property Rights and Other Matters ..35 Turning on the main power.........16 Mounting Precautions Turning power on ............16 (For SHARP dealers and service engineers) ....36 Turning power off ............16...

  • Page 9: Supplied Components

    Supplied Components If any components are missing, please contact your dealer.  Liquid Crystal Display Monitor: 1  USB A to B cable (for touch back): 1  IoT sensor hub: 1  Power cord: 1  Cable clamp: 1 ...

  • Page 10: Part Names

    Part Names nFront view 9 10 11 12 13 3 4 5 6 7 1. USB port for external source (USB 3.0 compliant) (See 8. INPUT button (See page 21.) page 13.) 9. MENU button (See page 21.) 2. Pen Tray (See page 17.) 10.
  • Page 11 Part Names 24. HDMI input terminal (See page 12.) 25. Vents 26. AC input terminal (See page 15.) 27. Main power switch (See page 16.) 28. USB Type C output terminal (See page 13.) 29. USB port for storage expansion (USB 3.0 compliant) (See page 13.) 30.

  • Page 12: Connecting Peripheral Equipment

    Connecting Peripheral Equipment nRear view nFront view 1. USB Type C 1 input terminal Caution 2. USB Type C 2 input terminal • Be sure to turn off the main power switch and disconnect • Use the USB Type C cable (supplied). the plug from the power outlet before connecting/ • You can connect a device that supports DisplayPort disconnecting cables. Also, read the manual of the alternate mode.
  • Page 13 Connecting Peripheral Equipment 8. LAN 2 terminal • You can connect to the Internet by connecting a commercially available LAN cable between this terminal and a network. 9. LAN 1 terminal • By connecting this terminal to a network, you can connect an external device connected via USB to the network. 10. USB port for storage expansion (USB 3.0 compliant) • You can expand the storage used by the main system on this terminal by inserting a commercially available USB storage drive.

  • Page 14: Mounting An Iot Sensor Hub

    Mounting an IoT sensor hub It is possible to mount an IoT sensor hub in the following position. IoT sensor hub 1. Attach the supplied IoT sensor hub mounting brackets mounting bracket (L/R) to the IoT sensor hub with the supplied IoT sensor hub screws (M3) (x2).

  • Page 15: Connecting The Power Cord

    Connecting the Power Cord Caution • Use only the power cord supplied with the monitor. Main power switch 1. Turn off the main power switch. 2. Plug the power cord (supplied) into the AC input terminal. 3. Plug the power cord (supplied) into the power outlet. AC input terminal For power outlet Power cord (Supplied)

  • Page 16: Turning Power On/Off

    Turning Power On/Off nOperations after first power-on Caution When the monitor is turned on for the first time after being • Turn on the monitor first before turning on the computer or shipped from the factory, the setting screen will be displayed. playback device. Configure the settings according to the screen. • When switching the main power switch or the POWER button off and back on, always wait for at least 5 seconds.

  • Page 17: Touch Pen

    Touch Pen Eraser TIPS • Incorrect operation may result if your finger is too close to the tip of the pen. • Hold the touch pen with your bare hand. The screen will not respond if you wear a glove. • When multiple touch pens are used, touch positions and touch pen information (color, thickness, etc.) may become interchanged, and lines may break. - When touched simultaneously. - When touch pens are moved near each other. • Do not press the pen tip on other than the screen. This may cause malfunctioning. • If the pen tip becomes worn or damaged, replace the touch pen. To purchase a new touch pen, consult your dealer.

  • Page 18: Touch Action

    Touch action Touch action Double-tap Same action as double-clicking a mouse. Touch actions that can be used with this monitor differ Quickly touch twice with your finger/touch pen. according to operating system and application. The functions of touch actions are also different. For details, check operating system Help and the application’s support documentation.
  • Page 19 Touch action nFinger actions Drag-and-drop Same action as drag-and-drop with a mouse. Zoom Touch the screen with your finger/touch pen and move without Use in a screen that is capable of enlargement/reduction. lifting. When you have finished the movement, lift your finger/ Touch the screen with two fingers and move your fingers touch pen.

  • Page 20: Other Functions

    Touch action Rotate Use this action in a screen that is capable of image rotation. Touch the center point of the rotation with one finger. While holding that finger still, move another finger in the desired direction of rotation. Move another finger in the desired direction of rotation With one finger touching TIPS...

  • Page 21: Basic Operation

    Basic Operation Button Operation IoT accessories Operation 1. Camera module Camera module build with camera and Mic array. Which provide conference video function. Camera IoT sensor Hub 5 4 3 1. POWER button See page 16. 2. VOLUME DOWN / UP buttons 2.1 No device connection Controlling this monitor volume up/down.

  • Page 22: Using The Remote Control Unit (Option)

    Basic Operation Using the remote control unit (option) 1. POWER When “Operation Mode” is set to “Mode1” Press the POWER button to turn the power OFF (standby mode). When “Operation Mode” is set to “Mode2” When you press the POWER button, the backlight will be turned off.

  • Page 23: Menu Items

    Menu Items Displaying the menu Dashboard Button 1. Home screen The Home Screen is the default screen that users will see when they launch this monitor. Displays the measurement results of the IoT sensor. (Temperature, Humidity, CO2 Levels, TVOC Levels, Motion) Home Button The Home button can be tapped at any time to get the...
