FIELDBUS COMMUNICATION PROTOCOLS (SERIAL TYPE = DAT11)
The following table lists the output area registers (written by the master and acquired by the instrument) common
to all PROFINET, ETHERCAT, ETHERNET/IP, PROFIBUS and DEVICENET fieldbuses.
The registers are 16 bits in size. The registers written by the master in the output area, are read by the instrument with
a maximum frequency of 125 Hz (80 Hz in case of PROFIBUS fieldbus).
The size of the output area configured in the fieldbus master must match the size configured in the instrument.
Register
OUTPUT AREA REGISTER
address
1 Data Register (MSB)
2 Data Register (LSB)
3 Command Register
4 Load cell capacity (MSB)
5 Load cell capacity (LSB)
6 Load cell sensitivity
7 Weight division value
8 Weight filter factor
9 Weight stability factor
10 Autozero threshold (MSB)
11 Autozero threshold (LSB)
12 Zero tracking factor
13 Zero band
14 Delta weight
15 Monitor register
STATUS REGISTER CODING TABLE

Bit

15
Description Not
used
Bit
Description Not
calibrated
COMMAND REGISTER CODING TABLE
Register value
0x0001 Semi-automatic zero
0x0002 Auto-tare
0x0003 Peak reset
0x0010 Zero weight calibration
0x0011 Calibration of Scale Bottom weight
0x0020 Data storage in permanent memory
0x7FFF Direct memory access (Fieldbus only, no Modbus)
I
The value in the data register must be present when the command register is programmed
DAT700 Instrument User Manual
Int 16 bits
Int 16 bits
See related table.
See related table.
Int 16 bits
Int 16 bits
14 13
Not Not
used used
7 6 5
Weight Over-
load
error
COMMAND REGISTER FUNCTION
12 11
Not Not
used used
4 3
Under-load Tare
entered
Notes
10 9
Not
Memory
used
flag
2 1
Zero Stable
band weight
DATA REGISTER FUNCTION
-
-
-
-
Sample weight
-
8
Not
used
0
Zero center
pag. 47
