Pavone Systems DAT 700 Technical Manual page 15

Sub Message
Menu
FACTOR
C. RATE
AVERAG.
F1LTER
MONOT.
T.OSC1L.
R.OSC1L.
These parameters are available only if Factor = MANUAL is selected
**) When switching from 12.5 Hz to a higher frequency, or vice versa, the weight on the scale must be stable, otherwise an
error message is displayed.
*) Only in case of filter factor programmed to "MANUAL", this parameter value is independently programmable. Conversely, in
case of filter factor programmed to a predetermined value, the value of the following parameters is also predefined, according to
the following table.
Settling Time
Factor (Hz)
MANUAL
[0]
50 [1]
25 [2]
10 [3]
5 [4]
2 [5]
1.25 [6]
1 [7]
0.7 [8]
0.5 [9]
For Fieldbus or MODBUS settings, set index from [0] to [9].
DAT700 Instrument User Manual
Name
Filter factor
**
Output rate ADC
*
**
Average reading
numbers*
Monotony Time*
Oscillations Time*
Oscillations Range*
Freq ADC
(mS) (Hz)
Selectable
20 250
40 100
100 50
200 50
500 50
800 12.5
1000 12.5
1500 12.5
2000 12.5
FILTER MENU
Description
Filter response (Hz)
Weight acquisition
frequency (Hz)
Number of readings
counted for the filter
Evaluation time in case
of signal changes (in mS)
Time factor used to
recognize repetitive
signal oscillations.
(in mS)
Reference signal width
to detect repetitive
signal oscillations. (in
weight divisions)
Monotony
N readings
Time (mS)
Settable Settable
5 20
5 40
5 80
10 100
25 250
10 300
12 400
19 500
25 600
Type Default
Sel. 2 Hz
Filter Factor
Sel.
Dependent
Factor
Com.
Dependent
Factor
Com.
Dependent
Factor
Com.
Dependent
Factor
Com.
Dependent
Oscillations Oscillations
Time (mS)
Settable
4000
3000
2500
2000
1500
1500
1500
1200
1000
Range Ind.Fi
eldbus
See table 1201
12,5 [0]
50 [1]
1202
100 [2]
250 [3]
1000 [4]
0 ÷ 50 1203
0 ÷ 999 1204
0 ÷ 9999 1205
0 ÷ 99 1206
Range (div)
Settable
10
12
16
20
25
25
25
30
30
pag. 15
