This function allows downloading or uploading of the instrument setup memory.
Download function: instrument setup parameters are stored in a file.
•
Upload function: the instrument is configured with the setup parameters read from a file.
•
To use these functions, it is necessary to enable the relevant procedure ("receive file" or "transmit file") in the
TESTER 1008 instrument.
I
The handheld TESTER 1008 must be connected to the serial COM1 (Rs232) of the instrument.
Sub Message
Menu
RANGE
MODE
AN 0
ANALOG
AN FS
0 ADJ.
FS.ADJ.
(*)
The analog output is factory calibrated for each selectable range. This additional procedure is available to the user for adjustment
for each selectable range. In case of complete reset of the setup memory (with PC configurator) the factory calibrations are
reestablished.
DAT700 Instrument User Manual
SETUP MEMORY UPLOAD/DOWNLOAD
ANALOG OUTPUT SETTINGS
Name
Analog Selection of analog output type
output
range
Analog
Transmitted value selection
output
with analog output.
mode
Fixed tare Analog output offset
It is the weight corresponding
to the Scale Bottom of the
Scale
analog output, which may be
Bottom
different from the range of the
weighing system.
Procedure available to the user
Zero
for zero adjustment (*)
adjustment
Procedure available to the user
Scale
for Scale Bottom adjustment (*)
Bottom
adjustment
Description Type Default
Sel. 0– 10V
Sel. NET
0
Com.
Maximum
Com.
capacity
Spc
Spc
Range Ind.Fi
e
ldbus
0-10V [0]
0-5V [1]
1506
4-20mA [2]
0-20mA [3]
NET [0]
GROSS [1]
1505
PEAK [2]
1501
(MSB
)
1502
(LSB)
1503
(MSB)
0 –Capacity
1504
(LSB)
